Associated Numbers
0001326020 0001362010 0001362020 0001362042 0001362093 10693L 10693P 110443 120-30104 17644N 17644R 20405501 25-0334 260-62139 26148 26148A 26199 26199A 26283 26283A 26283H 26283J 26375 26422 27417 27417A 27417B 27417D 27417E 27435 27478 27478A 27478B 27486D 2873A010 2873A102 6025105 700.004.103 8212536 88212536 8EA012527-091 8EA730209-001 9000143402 9000143413 91-15-7087 997267 CS693 CST25105AS CST25105GS EAA-121270 LRS00124 SG0156 STL0693 STR25023 UD16578SSpecifications
Kilowatt | 2.4 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 28.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HESSTON | 300M | ||
MASSEY FERGUSON | 3085 | [Q1006-6] | 01.1992-12.1993 |
MASSEY FERGUSON | 3095 | [Q1006-6] | 01.1990-12.1994 |
MASSEY FERGUSON | 3635 | [Q1006-6T] | 01.1992-12.1994 |
NISSAN | Patrol 2.8 D | [A428] | 01.1984-12.1989 |
NISSAN | Patrol 2.8 TD | [A428T] | 01.1984-12.1989 |
PERKINS | D3.152 | [D3.152] |
Reference Information
1362093 0001362093 6025105 700.518.103 2873A010 1873A010 1362019 8EA012527-091 27486 25-0334 SG0156 STRJ685 1362010 26283A 26283H 88212536 2873141 220741 D11E74 27417 26283 2873D003 LRS00124 1326020 GXE4596 10693L 17644N 20405501 10693P EAA-121270 AES1124 000986023510 22.0693M 31179 26375 25-1400 0001326020 S0762S 22.0693 27486D 26148 26422 27478 986023510 STL0693 1447586M91 26383 20405501OE DRS3336 1362020 997267 27417E 26383J 92029 20500124 STR25023 26196 26199 260-62139 2873A10 STRL026 ADU1239 0001362042 27417B CGB-23336 27417A CST25105AS 0001362048 27417D 8212536 254460R 2873A102 UD16578S 120-30104 26383A CS693 1362042 8735 26383H 1362048 17644R 110443 CGB-23285 8EA730209-001 0009000143413 S12BH0684A2 26148A 9000143413 S12-84 0001362020 LRS124 33834 20405501BN 27478A 26283J 27478B STR10038 CST25105GS 27435 26283R 2873121 0009000143402 0001362019 91-15-7087 26199A 9000143402 MAV3610 0001362010 700.004.103 8735RVideo/Publications
0001326020 0001362010 0001362019 0001362020 0001362042 0001362048 0001362093 003-C952 0986023510 10693L 10693P 110443 120-30104 17644N 17644R 20405501 20405501BN 20405501OE 20500124 22.0693 22.0693M 25-0334 25-1400 254460R 260-62139 26148 26148A 26196 26199 26199A 26283 26283A 26283H 26283J 26375 26383 26383A 26383H 26383J 26422 27417 27417A 27417B 27417D 27417E 27435 27478 27478A 27478B 27486 27486D 2873A010 2873A102 33834 3C952 6025105 700.004.103 700.518.103 8212536 8735 8735R 88212536 8EA012527-091 8EA730209-001 9000143402 9000143413 91-15-7087 92029 997267 AES1124 CGB-23285 CGB-23336 CS693 CST25105AS CST25105GS D11E74 DRS3336 EAA-121270 LRS00124 LRS124 MAV3610 MTC952 S12-84 SG0156 STL0693 STR25023 STRJ685 STRL026 UD16578S 220741Add Your Number
