Associated Numbers
0001359104 0001362067 0986022750 10200L 10200P 11.130.579 110462 116137 120-30272 19083013 20405201 20500212 220737 23669 25-0064 260-62157 26211 26211A 26211D 26211E 26211H 26211L 26211N 26211Q 26211T 26211U 26338A 26338B 26338D 26338F 26339 26339A 26339B 26339D 26339E 26339F 26339H 26395 26395A 26395B 26395D 26395E 26395F 26925 27500 27500B 27500D 27500E 27500L 27569 27569A 27569B 27569D 27569E 27614 33379 590.001.103 6025102 72735974 8048 88212669 8EA726026-001 AZJ3182 CS200 CST25102AS CST25102GS D1NN-11000-A D2NN-11000-B D4NN-11000-B D7NN-11000-B D8NN-11000-BA D8NN-11000-CA D8NN-11000-CE D9NN-11000-AA EAA-111518 FONN-11000-CA GG5 IS0579 LRS00212 MS228 MS346 SG0148 STB1987 STM2003 STR25031 UD16576SSpecifications
| Kilowatt | 2.8 kW |
| Length (L.1) | 293 mm |
| Mount Hole Center - Center (O.1) | 103.5 mm |
| Mount Hole Center - Center (O.2) | 146 mm |
| Mount Hole Center - Center (O.3) | 103.5 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 580F | ||
| DAVID BROWN | 1410 | ||
| DAVID BROWN | 1412 | ||
| FORD | 2000 | 01.1964-12.1975 | |
| FORD | 2600 | 01.1975-12.1981 | |
| FORD | 2910 | 01.1981-12.1984 | |
| FORD | 3000 | 01.1964-12.1975 | |
| FORD | 3600 | 01.1975-12.1981 | |
| FORD | 3610 | 01.1981-12.1983 | |
| FORD | 3910 | 01.1982-12.1984 | |
| FORD | 4000 | 01.1964-12.1975 | |
| FORD | 4100 | 01.1975-12.1981 | |
| FORD | 4110 | 01.1981-12.1989 | |
| FORD | 4130 | 01.1990-12.1995 | |
| FORD | 4600 | 01.1975-12.1981 | |
| FORD | 4610 | 01.1981-12.1989 | |
| FORD | 4830 | 01.1990-12.1993 | |
| FORD | 5000 | 01.1965-12.1975 | |
| FORD | 5600 | 01.1975-12.1981 | |
| FORD | 5610 | 01.1981-12.1991 | |
| FORD | 5640 | 01.1992-12.1997 | |
| FORD | 655 | ||
| FORD | 655C | ||
| FORD | 6600 | 01.1975-12.1981 | |
| FORD | 6610 | 01.1981-12.1988 | |
| FORD | 6640 | 01.1992-12.1997 | |
| FORD | 6700 | 01.1976-12.1981 | |
| FORD | 6710 | 01.1981-12.1988 | |
| FORD | 7000 | 01.1972-12.1975 | |
| FORD | 7600 | 01.1975-12.1977 | |
| FORD | 7610 | 01.1982-12.1988 | |
| FORD | 7700 | 01.1976-12.1981 | |
| FORD | 7710 | 01.1981-12.1988 | |
| FORD | 7740 | 01.1992-12.1997 | |
| FORD | 7810 | 01.1988-12.1991 | |
| FORD | 7840 | 01.1992-12.1997 | |
| FORD | 8100 | 01.1979-12.1981 | |
| FORD | 8210 | 01.1982-12.1991 | |
| FORD | 8240 | 01.1992-12.1996 | |
| FORD | 8340 | 01.1992-12.1997 | |
| FORD | 8340T | 01.1994-12.1997 | |
| FORD | 8600 | 01.1973-12.1976 | |
| FORD | 8630 | 01.1990-12.1993 | |
| FORD | 8700 | 01.1977-12.1979 | |
| FORD | 8730 | 01.1990-12.1993 | |
| FORD | 8830 | 01.1990-12.1993 | |
| FORD | 9600 | 01.1973-12.1976 | |
| FORD | 9700 | 01.1977-12.1979 | |
| FORD | TW-10 | 01.1979-12.1982 | |
| FORD | TW-15 | 01.1983-12.1987 | |
| FORD | TW-20 | 01.1979-12.1982 | |
| FORD | TW-25 | 01.1983-12.1989 | |
| FORD | TW-30 | 01.1979-12.1982 | |
| FORD | TW-35 | 01.1983-12.1989 | |
| HEDEN | FC1000 | ||
| HYDREMA | 505 | ||
| HY-MAC | 105 | 01.1970-12.1972 | |
| HY-MAC | 270 | 01.1970- | |
| HY-MAC | 307 | 01.1970-12.1973 | |
| HY-MAC | 308 | 01.1970-12.1973 | |
| HY-MAC | 370 | 01.1970-12.1973 | |
| HY-MAC | 505 | 01.1970-12.1973 | |
| HY-MAC | 570 | 01.1970-12.1973 | |
| HY-MAC | 605 | 01.1970-12.1973 | |
| NEW HOLLAND | 4630 | 01.1990-12.1997 | |
| NEW HOLLAND | 5640 | 01.1992-12.1997 | |
| NEW HOLLAND | 6640 | 01.1992-12.1997 | |
| NEW HOLLAND | 7740 | 01.1992-12.1997 | |
| NEW HOLLAND | 7840 | 01.1992-12.1997 | |
| NEW HOLLAND | 8040 | 01.1985- | |
| NEW HOLLAND | 8240 | 01.1992-12.1996 | |
| NEW HOLLAND | 8340 | 01.1992-12.1997 | |
| NEW HOLLAND | 8340T | 01.1994-12.1997 |
Reference Information
590.001.103.108 81AB10300UB 26395 33379 D8NN11000CB 116137 590.001.103.110 11.130.579 D8NN-11000-BA STB1987 71YB11000AA 10200L 27569E D0NN11000B D0NN11000A 27569D 20500212 9142765 D8NN-11000-CE 590.001.103.100 SG0148 K308650 D8NN-11000-CA 27569A 27569B 23669 27500 STL0200 C7NN11000A C7NN11000B GG5 0001362067 26211Q 26211N 26211T 26211U 8048 UD16576S 330259 ANM15417 590.001.103.321 LRS212 88212669 590.001.103.325 S0761S S12LU0154A2 17646N 110462 27569 87318759 26211A 702000150 LRS00212 26211D CS200 26211E D9NN-11000-AA 26211H 590.001.103.310 26211L AZJ3198 STM2003 26925 C6NF11000A S12LU0154 LES0017-N 330352 26339D 27614 26339B 26339A 26339H 26339F 26339E 26395B 26395A D2NN-11000-B FONN-11000-CA 26395F 26395E F0NN-11000-CA 26395D AZJ3182 S13-61 27500B 220737 27500D 27500E 16608N-M50 D1NN-11000-A 26339 26338B 26338A 27500L GSLRS212L-R 26338F 26338D D8NN11000AA 26211 590.001.103.016 D7NN-11000-B 72735974 SSLRS212L-R S13-61A IS0579 MS346 STR7946 311562 STR25012 25-0064 D4NN-11000-B 1516712R 1362067Video/Publications
0001359104 0001362067 0986022750 10200L 10200P 11.130.579 110462 116137 120-30272 19083013 20405201 20500212 220737 23669 25-0064 260-62157 26211 26211A 26211D 26211E 26211H 26211L 26211N 26211Q 26211T 26211U 26338A 26338B 26338D 26338F 26339 26339A 26339B 26339D 26339E 26339F 26339H 26395 26395A 26395B 26395D 26395E 26395F 26925 27500 27500B 27500D 27500E 27500L 27569 27569A 27569B 27569D 27569E 27614 33379 590.001.103 6025102 72735974 8048 88212669 8EA726026-001 ALTE580 AZJ3182 CGB-23520 CS200 CST25102AS CST25102GS D1NN-11000-A D2NN-11000-B D4NN-11000-B D7NN-11000-B D8NN-11000-BA D8NN-11000-CA D8NN-11000-CE D9NN-11000-AA EAA-111518 FONN-11000-CA GG5 IS0579 LRS00212 LRS212 MAV3620 MAV3810 MS 346 MS228 MS346 SG0148 STB1987 STM2003 STR25031 STRL025 STRS074 UD16576SAdd Your Number
