Associated Numbers
0001153006 02E911024C 02E911024CX 0986026160 115539 116156 220590 25-5030 254548B 254548V 255319B 255319V 300.901.132 30271N 3312 42026160 438000-0251 6010582 88214681 8EA012140-041 8EA012528-581 8EA738259-421 AEY3857 CST10582 CST10582AS CST10582ES CST10582GS CST10582OS CST10582RS DRS1155 DS2265 DSN1460 EAA-123087 EAA-123088 LRS03857 S0632S STV2319 UD13943S AS-PLList AS-PL AUTOELECTRO 0001153005 BOSCHList BOSCH CARGO CASCO CEVAM DELCO DENSO EAA ELSTOCK ERA HELLA HERTH+BUSS KRAUF KUHNER LUCAS POWERMAX PSH SANDO VW WAI / TRANSPO Bosch 02E911024H ruil 11026160 EuroTec 11090233 Cargo 207672 Valeo 300901132 4280008320 Denso 4380000250 4380000251 438259 458419 8080386F Friesen 911155 EDR Remy Lucas 02E911022C 70-1331 02E911022CX 02E911023Q 02E911023QX 02E911023T 02E911023TX 02E911024HX 02E911024J 02E911024JX 12237 EAI 254146 Elstock 300931132 4380800251 438291 438339 458718 910767 DRS0767 ESW20ER25 LRS02474 RSW20R10 S3153S UD13041S AEY2474 CST15131 CST15131AS CST15131ES CST15131GS CST15131OS CST15131RS 3058 428000-8320 438000-0250 25-4146 8080386 FRIESEN STB2319 STB7319 22.3014 LAUBER 8214289 8214434 88214434 6015131 VALEOList ESW20ER25HE VALEO ESW20ER25PK2 02E911023M 30271R STR54161 WOODAUTO VAL438291 VALESW20ER25
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 246 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 43 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 79 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | Q3 2.0 TDi | [CUVC] | 01.2015- |
| AUDI | Q3 2.0 TDi | [CUVD] | 01.2015- |
| AUDI | Q3 2.0 TDi | [CUWA] | 01.2015- |
| AUDI | Q3 2.0 TDi Qauttro | [CLLB] | 01.2015- |
| AUDI | Q3 2.0 TDi Qauttro | [CUVC] | 01.2015- |
| AUDI | Q3 2.0 TDi Qauttro | [CUWA] | 01.2015- |
| SKODA | Superb 2.0 TDi | [CFFB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi | [CFGB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi 4x4 | [CFFB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi 4x4 | [CFGB] | 01.2010-12.2015 |
| VW | Caddy 2.0 TDi | [CFHC] | 01.2015- |
| VW | Caddy 2.0 TDi | [CUUB] | 01.2015- |
| VW | Caddy 2.0 TDi | [CUUD] | 01.2015- |
| VW | Caddy 2.0 TDi | [DFSB] | 01.2015- |
| VW | Caddy 2.0 TDi | [DFSD] | 01.2015- |
| VW | Caddy 2.0 TDi 4-Motion | [CFHC] | 01.2015- |
| VW | Caddy 2.0 TDi 4-Motion | [CUUB] | 01.2015- |
| VW | Caddy 2.0 TDi 4-Motion | [DFSB] | 01.2015- |
| VW | CC 2.0 TDi | [CUVC] | 01.2015- |
| VW | CC 2.0 TDi | [CUWA] | 01.2015- |
| VW | Golf VI 2.0 TDi | [CUUB] | 01.2015- |
| VW | Jetta 2.0 TDi | [CUUA] | 01.2014- |
| VW | Jetta 2.0 TDi | [CUUB] | 01.2014- |
| VW | Jetta 2.0 TDi | [DELA] | 01.2014- |
| VW | Multivan 2.0 TDi | [CXEB] | 01.2015- |
| VW | Multivan 2.0 TDi | [CXFA] | 01.2015- |
| VW | Multivan 2.0 TDi | [CXHA] | 01.2015- |
| VW | Multivan 2.0 TDi 4-Motion | [CXEB] | 01.2015- |
| VW | Multivan 2.0 TDi 4-Motion | [CXFA] | 01.2015- |
| VW | Multivan 2.0 TDi 4-Motion | [CXHA] | 01.2015- |
| VW | New Beetle 2.0 TDi | [CUUA] | 01.2014- |
| VW | New Beetle 2.0 TDi | [CUUB] | 01.2014- |
| VW | New Beetle 2.0 TDi | [DELA] | 01.2014- |
| VW | Passat 2.0 TDi | [CFFB] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi | [CFGB] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi | [CFGC] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi | [CLLA] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi 4-Motion | [CFFB] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi 4-Motion | [CFGB] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi 4-Motion | [CFGC] | 01.2013-12.2014 |
| VW | Passat 2.0 TDi 4-Motion | [CLLA] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi | [CFFB] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi | [CFGB] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi | [CFGC] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFFB] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFGB] | 01.2013-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFGC] | 01.2013-12.2014 |
| VW | Passat CC 2.0 TDi | [CFFA] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFFB] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFGB] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFGC] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CLLA] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CUVC] | 01.2015- |
| VW | Passat CC 2.0 TDi | [CUWA] | 01.2015- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFFA] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFFB] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFGB] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFGC] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CLLA] | 01.2011- |
| VW | Scirocco 2.0 TDi | [CFHB] | 01.2010-12.2014 |
| VW | Scirocco 2.0 TDi | [CFHC] | 01.2010-12.2014 |
| VW | Scirocco 2.0 TDi | [CUUB] | 01.2014- |
| VW | Scirocco 2.0 TDi | [CUWA] | 01.2014- |
| VW | Scirocco 2.0 TDi | [CUXA] | 01.2014- |
| VW | Sharan 2.0 TDi | [CUVC] | 01.2015- |
| VW | Sharan 2.0 TDi | [CUWA] | 01.2015- |
| VW | Sharan 2.0 TDi | [DFLA] | 01.2015- |
| VW | Sharan 2.0 TDi | [DFMA] | 01.2015- |
| VW | Sharan 2.0 TDi 4-Motion | [CUVC] | 01.2015- |
| VW | Sharan 2.0 TDi 4-Motion | [DFLA] | 01.2015- |
| VW | Sharan 2.0 TDi 4-Motion | [DFMA] | 01.2016- |
| VW | Tiguan 2.0 TDi | [CUVC] | 01.2015- |
| VW | Tiguan 2.0 TDi 4-Motion | [CUVC] | 01.2015- |
| VW | Tiguan 2.0 TDi 4-Motion | [CUWA] | 01.2015- |
| VW | Transporter 2.0 TDi | [CXEB] | 01.2015- |
| VW | Transporter 2.0 TDi | [CXFA] | 01.2015- |
| VW | Transporter 2.0 TDi | [CXHA] | 01.2015- |
| VW | Transporter 2.0 TDi 4-Motion | [CXEB] | 01.2015- |
| VW | Transporter 2.0 TDi 4-Motion | [CXFA] | 01.2015- |
| VW | Transporter 2.0 TDi 4-Motion | [CXHA] | 01.2015- |
Reference Information
0001153005 1153005 88214681 255319V 02E911023TX CST10582RS 1153006 0001153006 254548V DSN1460 3312 STR1929 8EA738259-421 EAA-123088 438080-0251 8EA012528-581 EAA-123087 LRS3857 02E911024H 255319B CST10582GS 02E911022HX 02E911024J 6010582 220590 02E911024HX CST10582 02E911024C CST10582OS 02E911024B DS2265 UD13943S 986026160 42026160 S0632S 02E911023T 2E911024H 02E911024CX 02E911023Q 8EA012140-041 AEY3857 115539 CST40477GS 2E911024B 02E911023M 2E911023T 116156 02E911022CX 3058 2E911023TX S12BH0145A2 438000-0250 S12DE0145 2E911023M 02E911023QX 30271N 438000-0251 STM1256 2E911023Q ESW20ER25 02E911023MX ESW20ER25HE 254548B CST15131GS 2E911023QX CST40477 02E911024BX CST10582ES 8080386 STV2319 CST15131 300.901.132 02E911024JX 02E911022H CST10582AS 02E911022C 2E911024BX DRS1155 25-5030 000986026160 LRS03857Video/Publications
0001153005 0001153006 02E911024C 02E911024CX 0986026160 115539 116156 220590 25-5030 254548B 254548V 255319B 255319V 300.901.132 30271N 3312 42026160 438000-0251 6010582 88214681 8EA012140-041 8EA012528-581 8EA738259-421 AEY3857 CST10582 CST10582AS CST10582ES CST10582GS CST10582OS CST10582RS DRS1155 DS2265 DSN1460 EAA-123087 EAA-123088 LRS03857 LRS3857 S0632S STV2319 UD13943SAdd Your Number
