Associated Numbers
0001108217 0001115008 0051517401 005151740180 063521082170 0986021260 101172 101172B 11937 20401372 220146 25-2358 25-3329 32439N 32440R 3870 42018180 42021260 458642 550.513.102 6.7024.1 6010273 88213234 8EA012526-341 8EA737708-001 944280181800 A0051517401 A005151740180 BOS0001108217 CS1172 CST10273 CST10273AS CST10273ES CST10273GS CST10273OS CST10273RS DRT1260 DT2370 EAA-121258 LRS01440 LRS01967 MRS18180 MSN2081 SG0581 STB1172 STR50362Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 226 mm |
Mount Hole Center - Center (O.1) | 99 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 14.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | A 160 2.0 CDi | (W169)[OM640.942] | 01.2004- |
MERCEDES BENZ | A 180 2.0 CDi | (W169)[OM640.940] | 01.2004- |
MERCEDES BENZ | A 200 2.0 CDi | (W169)[OM640.941] | 01.2004- |
MERCEDES BENZ | B 180 2.0 CDi | (W245)[OM640.940] | 01.2005- |
MERCEDES BENZ | B 200 2.0 CDi | (W245)[OM640.941] | 01.2005- |
MERCEDES BENZ | Vaneo 1.7 CDi | (414)[OM668.914] | 01.2002-12.2005 |
Reference Information
CST10273AS LRS1440 88213234 5151740180 CST10273ES STR1496 EAA-121258 0001115008 A0051511601 25-3329 8EA737708-001 1115008 25-2358 CS1172 MAV123290 LRS1967 986021260 S12BH0100A2 CST10273 331324 220146 20401372 DT2370 101172B 9.4428E+11 32439N CST10273RS SG0581 STR50362 51517401 550.513.102 458642 MRS18180 8EA012526-341 0001108217 101172 CST10273GS STB1172 MAV122730 A0051517401 A005151740180 CST10273OS LRS01440 S12BH0100 6010273 BOS0001108217 42018180 LRS01967 MSN2081 63521082170 1108217 32440R 000986021260 6.7024.1 3870 DRT1260 42021260 STRL152 11937 51511601Video/Publications
0001108217 0001115008 0051517401 005151740180 063521082170 0986021260 101172 101172B 11937 20401372 220146 25-2358 25-3329 32439N 32440R 3870 42018180 42021260 458642 550.513.102 6.7024.1 6010273 88213234 8EA012526-341 8EA737708-001 944280181800 A0051517401 A005151740180 BOS0001108217 CS1172 CST10273 CST10273AS CST10273ES CST10273GS CST10273OS CST10273RS DRT1260 DT2370 EAA-121258 LRS01440 LRS01967 LRS1440 LRS1967 MAV122730 MAV123290 MRS18180 MSN2081 SG0581 STB1172 STR50362 STRL152Add Your Number
