Associated Numbers
0001109377 0001109378 0001109401 0001109402 04801849AB 04801849AC 12316 25-4295 255015 255015B 6010528 68100366AA 830.927.102 BOS0001109401 CST10528 CST10528AS CST10528ES CST10528GS CST10528OS CST10528RS DRS0608 LRS02622 STB9401 UD13023SSpecifications
Kilowatt | 2.5 kW |
Length (L.1) | 256 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 37 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JEEP | Cherokee 2.8 CRD | [ENS] | 01.2009- |
JEEP | Wrangler 2.8 CRD | [ENS] | 01.2011- |
Reference Information
1109402 6010528 1109401 CST10528ES CST10528GS CST10528AS 68100366AA 830.927.102 255015 4801424AB S12BH0396A2 0001109377 0001109378 UD13023S 12316 25-4295 CST10528RS STR10172 LRS2622 BOS0001109401 STB9401 4801849AC 1109378 1109377 4801849AB 04801424AB 04801849AC 255015B 04801849AB 04801849AA CST10528 S0619S DRS0608 LRS02622 CST10528OS STRF111 0001109401 0001109402Video/Publications
0001109377 0001109378 0001109401 0001109402 04801849AB 04801849AC 12316 25-4295 255015 255015B 6010528 68100366AA 830.927.102 BOS0001109401 CST10528 CST10528AS CST10528ES CST10528GS CST10528OS CST10528RS DRS0608 LRS02622 LRS2622 STB9401 STRF111 UD13023SAdd Your Number
