Associated Numbers
0001108207 0001108228 0001108229 07C911023D 07C911023F 07C911023FX 19003N 200.518.093 255646 91-15-7270 EAA-122282 STR50621Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 225 mm |
Mount Hole Center - Center (O.1) | 28 mm |
Mount Hole Center - Center (O.2) | 115 mm |
Mount Hole Center - Center (O.3) | 16 mm |
Mount Hole Center - Center (O.4) | 101 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
Mount Hole Diameter (C.4) | M10x1.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A8 6.0 W12 Quattro | [BHT] | 12.2003-07.2010 |
Reference Information
STR1765 07C911023D 07C911023F EAA-122282 STRS396 255646 200.518.093 STR50621 19003N 91-15-7270 07C911023FX 1108207 1108229 1108228 0001108207 0001108229 0001108228Video/Publications
0001108207 0001108228 0001108229 07C911023D 07C911023F 07C911023FX 19003N 200.518.093 255646 91-15-7270 EAA-122282 STR50621 STRS396Add Your Number
