Associated Numbers
0001136002 0001136003 0001136007 0001136008 0986025180 115624 12275 220816 23300-00Q2C 23300-1073R 23300-1412R 23300-6124R 23300-7223R 25-4408 255037 255037B 255037M 255037V 3223 570.571.123 AEY2735 LRS02735 S0608S STR50610 UD13168S UD13766SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 213 mm |
Mount Hole Center - Center (O.1) | 30 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 107 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 0.5 mm |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | Citan 108 1.5 CDi | (415)[OM607.951] | 01.2013- |
MERCEDES BENZ | Citan 109 1.5 CDi | (415)[OM607.951] | 01.2013- |
MERCEDES BENZ | Citan 111 1.5 CDi | (415)[OM607.951] | 01.2013- |
NISSAN | Note 1.5 dCi | [K9K..] | 01.2013- |
NISSAN | Pulsar 1.5 dCi | [K9K..] | 01.2014- |
RENAULT | Captur 1.5 dCi | [K9K..] | 01.2013- |
RENAULT | Clio 1.5 dCi | [K9K608] | 01.2012- |
RENAULT | Clio 1.5 dCi | [K9K608] | 01.2013- |
RENAULT | Clio 1.5 dCi | [K9K612] | 01.2012- |
RENAULT | Clio 1.5 dCi | [K9K612] | 01.2013- |
RENAULT | Clio 1.5 dCi | [K9K618] | 01.2012- |
RENAULT | Clio 1.5 dCi | [K9K618] | 01.2013- |
RENAULT | Grand Scenic 1.5 dCi | [K9K?] | 01.2012- |
RENAULT | Kangoo 1.5 dCi | [K9K?] | 01.2013- |
RENAULT | Megane 1.5 dCi | [K9K?] | 01.2013- |
RENAULT | Scenic 1.5 dCi | [K9K?] | 01.2012- |
Reference Information
WOOSTR50661 AZMT-53-010-1376 LRS2735 AC-CBS5854 SBOA08A 12275 7711135334 CGB-54408 2330000Q3B DRS0935 STR1779 3121829 STR50610 3121827 3121828 23300-6124R 23300-1073R 233004868R 986025180 UD13766S WOOSTR50610 6010A08.0 6010A08.1 UD13168S 2040180ABN 10010A08OV 25-4408 F032115624 115624 S12BH0942 23300-00Q2C 23300-1412R V46-12-25180 CST10A08AS 570.571.123.281 SBOA08 23300-7223R 1136007 1136008 220816 106588 1136003 0001136003 332206 233007224R CGB-25180 0001136008 S0608S 0001136007 IR8264 570.571.123.210 570.571.123.010 330067122 2040180AOE 255037 30425N ST01892 1136002 30425R STRL124 570.571.123.018 000986025180 000F032115624 LRS02735 8EA011613-061 570.571.123.215 A25180 255037M BOS0001136007 42025180 BOS0001136008 WG2013381 233007689R PRSL124 10010A08AV 8200836473B 233001073 0001136002 3223 DS2045 255037V CST10A08GS 88212821 STM1345Video/Publications
0001136002 0001136003 0001136007 0001136008 0986025180 115624 12275 220816 23300-00Q2C 23300-1073R 23300-1412R 23300-6124R 23300-7223R 25-4408 255037 255037B 255037M 255037V 3223 570.571.123 AEY2735 LRS02735 LRS2735 S0608S STR50610 UD13168S UD13766SAdd Your Number
