S0594 - Brand new AS-PL Starter motor

Specifications

Kilowatt	5.5 kW
Length (L.1)	343 mm
Mount Hole Center - Center (O.1)	90 mm
Mount Hole Center - Center (O.2)	90 mm
Mount Hole Center - Center (O.3)	127 mm
Mount Hole Diameter (C.1)	10.5 mm
Mount Hole Diameter (C.2)	10.5 mm
Mount Hole Diameter (C.3)	10.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	13 qty
Pinion at Rest (B)	48.5 mm
Rotation	CW
Spigot Diameter (A)	89 mm
Unit Type	BOSCH
Voltage	24 V

Vehicle Applications

Make	Model	Type	Year
RENAULT	370.18 10.8	[DXi11]	10.2005-
RENAULT	370.26 10.8	[DXi11]	10.2005-
RENAULT	370.32 10.8	[DXi11]	10.2005-
RENAULT	380.18 10.8	[DXi11]	02.2013-
RENAULT	410.18 10.8	[DXi11]	10.2005-
RENAULT	410.24 10.8	[DXi11]	10.2005-
RENAULT	410.25 10.8	[DXi11]	10.2005-
RENAULT	410.26 10.8	[DXi11]	10.2005-
RENAULT	410.32 10.8	[DXi11]	10.2005-
RENAULT	450.18 10.8	[DXi11]	10.2005-
RENAULT	450.24 10.8	[DXi11]	10.2005-
RENAULT	450.25 10.8	[DXi11]	10.2005-
RENAULT	450.26 10.8	[DXi11]	10.2005-
RENAULT	450.32 10.8	[DXi11]	10.2005-
VOLVO	260 9.4	[D9B260]	06.2006-
VOLVO	310 9.4	[D9B310]	06.2006-
VOLVO	360 9.4	[D9B360]	06.2006-
VOLVO	B 9 9.4	[D9B310]	09.2005-
VOLVO	B 9 9.4	[D9B360]	09.2005-
VOLVO	FM 300 9.4	[D9A300]	09.2005-
VOLVO	FM 300 9.4	[D9B300]	09.2005-
VOLVO	FM 330 10.8	[D11C330]	04.2012-
VOLVO	FM 330 10.8	[D11K330]	04.2012-
VOLVO	FM 370 10.8	[D11C370]	04.2012-
VOLVO	FM 370 10.8	[D11K370]	04.2012-
VOLVO	FM 410 10.8	[D11C410]	04.2012-
VOLVO	FM 410 10.8	[D11K410]	04.2012-
VOLVO	FM 450 10.8	[D11C450]	04.2012-
VOLVO	FM 450 10.8	[D11K450]	04.2012-
VOLVO	FM 9/260 9.4	[D9A260]	12.2001-09.2005
VOLVO	FM 9/300 9.4	[D9A300]	12.2001-09.2005
VOLVO	FM 9/340 9.4	[D9A340]	12.2001-08.2005
VOLVO	FM 9/340 9.4	[D9A340]	12.2001-09.2005
VOLVO	FM 9/380 9.4	[D9A380]	12.2001-09.2005
VOLVO	FMX 330 10.8	[D11C330]	09.2013-
VOLVO	FMX 330 10.8	[D11K330]	09.2013-
VOLVO	FMX 370 10.8	[D11C370]	09.2013-
VOLVO	FMX 370 10.8	[D11K370]	09.2013-
VOLVO	FMX 410 10.8	[D11C410]	09.2013-
VOLVO	FMX 410 10.8	[D11K410]	09.2013-
VOLVO	FMX 450 10.8	[D11C450]	09.2013-
VOLVO	FMX 450 10.8	[D11K450]	09.2013-

Reference Information

220559 6010804 BOS0001261041 986024670 LRS3825 115877 6010804.1 20397219 M9T61471 254401P STM9497 CS1495 254401M S24BH0078A2 20401408BN UD13031S S0594 LRS03825 20401408OE 114193 MAV128040A 1261041 000986024670 M009T61471 0001261041 STR1905 45-4498 CST10804GS 561.504.133 EAA-121206 CST10804AS STM4497

Video/Publications

0001261041 114193 115877 20397219 254401M 254401P 45-4498 561.504.133 986024670 BOS0001261041 CS1495 EAA-121206 LRS03825 LRS3825 S0594 STM4497 STM9497 UD13031S 220559
