Associated Numbers
0001366029 254027 254027M UD12905SSpecifications
Kilowatt | 1.9 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20.5 mm |
Rotation | ACW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BPM | 620SH 12.0 | 01.1992-12.2002 | |
BPM | Ionic 127 3.0 | 01.1962-12.1977 | |
BPM | V12 / 570 12.0 | 01.1972-12.1992 | |
BPM | V12 / 620S 12.0 | 01.1972-12.1992 | |
BPM | Vulcano 375 8.0 | 01.1968-12.1992 | |
BPM | Vulcano 450 7.9 | 01.1968-12.1992 | |
LOMBARDINI | LDAM96 0.6 | 01.1966-12.1978 | |
RUGGERINI | RDK901/2 1.1 | 01.1980-12.1994 | |
RUGGERINI | RDM901 1.1 | 01.1977-12.1990 | |
RUGGERINI | RDM901 1.1 | 01.1991-12.2001 | |
RUGGERINI | RDM901/2 1.1 | 01.1978-12.1994 | |
RUGGERINI | RDM902 1.1 | 01.1977-12.1990 | |
RUGGERINI | RDM902 1.1 | 01.1991-12.2001 |
Reference Information
UD12905S 71-15-18468 1354089 0001354089 MAV123450 33337 EAA-111170 0001366029 1366013 S0560 0001366013 S12BH0302A2 1366029Video/Publications
0001354089 0001366013 0001366029 33337 71-15-18468 EAA-111170 MAV123450 UD12905SAdd Your Number
