Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 244.79 including GST
NZ$ 212.86 excluding GST
or four payments of $61.20
with
Learn More
UOM:
each
Product Code:
S0544
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
F000CD09A0Associated Numbers
0986019301 101125 101379H 101379K 101379V 114123 20404461 25-2416 31282N 495108 51888975 55209989 6030110 8000090 BOSF000CD0A01 CST30110 CST30110AS CST30110ES CST30110GS CST30110OS CST30110RS F000AL0309 F000AL0310 F000C60001 F000C60004 F000CD0900 F000CD0903 F000CD09A0 F000CD09A3 F000CD0A01 LRS01474 S0544 STB8975 TSC1015 UD12062SSpecifications
| Kilowatt | 0.80 kW |
| Length (L.1) | 183 mm |
| Mount Hole Center - Center (O.1) | 67 mm |
| Mount Hole Center - Center (O.2) | 108 mm |
| Mount Hole Center - Center (O.3) | 72 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | 9.50 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 9.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Doblo 1.3 MPI | 01.2001-12.2006 | |
| FIAT | Doblo 1.4 MPI 16V | 01.2009- | |
| FIAT | Doblo 1.4 MPI 8V | 01.2009- | |
| FIAT | DOBLO Box Body/MPV (223_) 1.2 (223ZXA1A) | 223A5.000 | 03.2001-01.2004 |
| FIAT | DOBLO MPV (119_, 223_) 1.2 (223AXA1A) | 223A5.000 | 03.2001- |
| FIAT | Fiorino 1.4 Flex | 12.2013- | |
| FIAT | Fiorino Furgao 1.3 MPI 8V Flex | 01.2003-12.2013 | |
| FIAT | Idea 1.4 Flex | 01.2005-12.2010 | |
| FIAT | Palio 1.0 | 01.2002- | |
| FIAT | Palio 1.3 | 01.2002- | |
| FIAT | Palio 1.4 MPI 8V | 01.2002- | |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A1.000 | 04.1996-10.2003 |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A3.011 | 04.1996-10.2003 |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 176A8.000 | 06.1998- |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 178B5.000 | 06.1998- |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 178B7.045 | 07.1997-08.2002 |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 178C4.066 | 07.1997-08.2002 |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 178E2.000 | 06.1998- |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 178E2.000 | 06.1999-10.2000 |
| FIAT | PALIO (178_, 171_, 371_) 1.2 | 188A4.000 | 07.1997-08.2002 |
| FIAT | Palio Weekend 1.0 | 01.2000- | |
| FIAT | Palio Weekend 1.3 | 01.2000- | |
| FIAT | Palio Weekend 1.4 16V | 01.2000- | |
| FIAT | Palio Weekend 1.4 8V | 01.2000- | |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.2 | 178B5.000 | 04.1996-02.2004 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.2 (178BXZ1A) | 178E2.000 | 06.1999-10.2002 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (1788891, 1789491, 1730250) | 178D6.011 | 03.2000-02.2003 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (1788891, 1789491, 1730250) | 188A5.000 | 03.2000-02.2003 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (178DYE1A, 178DYE1AAP, 178DYE1AAT) | 178D6.011 | 09.2001-10.2004 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (178DYE1A, 178DYE1AAP, 178DYE1AAT) | 188A5.000 | 09.2001-10.2004 |
| FIAT | PANDA (141_) 1000 4x4 | 141C2.000 | 05.1986-12.1994 |
| FIAT | PANDA (141_) 1000 4x4 | 156A2.246 | 05.1986-12.1994 |
| FIAT | PANDA (141_) 1000 4x4 | 156A3.000 | 01.1986-12.1992 |
| FIAT | PANDA (141_) 1000 i.e. Cat | 141C2.000 | 10.1987-08.1998 |
| FIAT | PANDA (141_) 1000 i.e. Cat | 156A2.246 | 10.1987-08.1998 |
| FIAT | PANDA (141_) 1100 | 156C.046 | 05.1991-12.1999 |
| FIAT | PANDA (141_) 1100 | 176B2.000 | 02.1995-09.2003 |
| FIAT | PANDA (141_) 1100 | 187A1.000 | 02.1995-09.2003 |
| FIAT | PANDA (141_) 1100 4x4 | 176B2.000 | 02.1995-07.2004 |
| FIAT | PANDA (141_) 1100 4x4 | 187A1.000 | 02.1995-07.2004 |
| FIAT | PANDA (141_) 1100 Trekking 4x4 | 156C.046 | 10.1991-07.2004 |
| FIAT | PANDA (141_) 750 | 156A4.000 | 01.1986-10.2003 |
| FIAT | PANDA (141_) 750 | 156A4.048 | 01.1986-10.2003 |
| FIAT | PANDA Hatchback Van (141_) 1000 i.e | 141C2.000 | 08.1992-02.2004 |
| FIAT | PANDA Hatchback Van (141_) 1000 i.e | 156A2.246 | 08.1992-02.2004 |
| FIAT | PANDA Hatchback Van (141_) 1.1 | 156C.046 | 05.1991-03.1995 |
| FIAT | PANDA Hatchback Van (141_) 1.1 | 187A1.000 | 09.2000-02.2004 |
| FIAT | PANDA Hatchback Van (141_) 1.1 4x4 | 187A1.000 | 09.2000-02.2004 |
| FIAT | PUNTO (188_) 1.2 16V 80 (188.233, .235, .253, .255, .333, .353, .639,... | 188A5.000 | 09.1999-04.2006 |
| FIAT | PUNTO (188_) 1.2 60 (188.030, .050, .130, .150, .230, .250) | 188A4.000 | 09.1999-12.2010 |
| FIAT | PUNTO (188_) 1.2 Bipower (188BXA1A) | 188A4.000 | 08.2001-05.2003 |
| FIAT | PUNTO (188_) 1.2 Natural Power | 188A4.000 | 09.2003-03.2012 |
| FIAT | PUNTO (188_) 1.2 Natural Power (188BXA1A) | 188A4.000 | 04.2004-04.2006 |
| FIAT | PUNTO Hatchback Van (188_) 1.2 60 | 188A4.000 | 02.2000-10.2009 |
| FIAT | PUNTO Hatchback Van (188_) 1.2 Natural Power (188CXA1A) | 188A4.000 | 01.2003-12.2010 |
| FIAT | SEICENTO / 600 (187_) 1.1 (187AXB, 187AXB1A, 187AXC1A02) | 176B2.000 | 01.1998-01.2010 |
| FIAT | SEICENTO / 600 (187_) 1.1 (187AXB, 187AXB1A, 187AXC1A02) | 187A1.000 | 01.1998-01.2010 |
| FIAT | SEICENTO / 600 Hatchback Van (287_) 1.1 (187CXB/C) | 176B2.000 | 01.1998-01.2010 |
| FIAT | Siena 1.0 | 01.2002-12.2012 | |
| FIAT | Siena 1.3 | 01.2002-12.2012 | |
| FIAT | Siena 1.4 MPI 8V Flex | 01.2002-12.2012 | |
| FIAT | SIENA (178_, 172_, 372_) 1.3 | 188A5.000 | 09.2001-12.2009 |
| FIAT | SIENA (178_, 172_, 372_) 1.3 (178CXG1AAM, 178CXG1AAP, 178CXG1AAT) | 178B5.000 | 09.1998-12.2002 |
| FIAT | Strada 1.3 | 01.2002-12.2006 | |
| FIAT | Strada 1.4 MPI 8V Flex | 01.2002-12.2006 | |
| FIAT | Strada 1.4 MPI 8V Flex | 01.2005- | |
| FIAT | STRADA Pickup (178_, 278_) 1.2 | 178B5.000 | 06.1999-12.2006 |
| FIAT | STRADA Pickup (178_, 278_) 1.2 | 188A4.000 | 04.2003- |
| FIAT | Uno 1.0 | 01.2001- | |
| FIAT | UNO (146_, 158_) 1.1 | 160A3.000 | 04.1986-06.2006 |
| FIAT | Uno 1.4 Flex | 01.2001- |
Reference Information
| 0986019301 | BOSCH |
| 0986B05008 | BOSCH |
| 0986B05009 | BOSCH |
| 101125 | KUHNER |
| 11019300 | EUROTEC |
| 201074 | VALEO |
| 20404011BN | REAL |
| 20404011OE | REAL |
| 20404011RC | REAL |
| 20404011RE | REAL |
| 20404911RC | REAL |
| 220516 | ERA |
| 25-2416 | ELSTOCK |
| 254286 | KUHNER |
| 254286L | KUHNER |
| 25-5113 | ELSTOCK |
| 256936R | KUHNER |
| 31282N | WAI |
| 318087092 | DRI |
| 318229092 | DRI |
| 42019301 | HERTH+BUSS |
| 432643 | VALEO |
| 446520 | VALEO |
| 455553 | VALEO |
| 458512 | VALEO |
| 46432262 | FIAT |
| 46465475 | FIAT |
| 46758241 | FIAT |
| 46763530 | FIAT |
| 46765839 | FIAT |
| 46796553 | FIAT |
| 46800155 | FIAT |
| 46843092 | FIAT |
| 495108 | VALEO |
| 500.026.083.440 | WAI |
| 500.035.093.265 | WAI |
| 55185057 | FIAT |
| 55201771 | FIAT |
| 55209989 | FIAT |
| 6030110.0 | SANDO |
| 6030110.1 | SANDO |
| 6030110.2 | SANDO |
| 6030110.4 | SANDO |
| 6030119.2 | SANDO |
| 63101003 | MAGNETI MARELLI |
| 63101008 | MAGNETI MARELLI |
| 63103028 | FIAT |
| 63103028010 | MAGNETI MARELLI |
| 71722372 | FIAT |
| 71722373 | FIAT |
| 71782359 | FIAT |
| 71782360 | FIAT |
| 71785851 | FIAT |
| 8000090 | DELCO |
| 8080064 | FRIESEN |
| 88212686 | POWERMAX |
| 885ST11 | STARTCAR |
| 8EA012526-771 | HELLA |
| 8EA737609-001 | HELLA |
| 943226391010 | MAGNETI MARELLI |
| 944280800640 | MAGNETI MARELLI |
| A19300 | ATL AUTOTECHNIK |
| AC-CBS1125 | ACAUTO |
| AZMT-53-010-1141 | A.Z. MEISTERTEILE |
| BST2549 | BORG & BECK |
| CST30110AS | CASCO |
| CST30110GS | CASCO |
| CST30110OS | CASCO |
| CST30110RS | CASCO |
| CST30119RS | CASCO |
| DRS3589 | DELCO |
| F000CD0001 | BOSCH |
| F000CD0900 | BOSCH |
| F000CD0903 | BOSCH |
| F000CD09A0 | BOSCH |
| F000CD09A3 | BOSCH |
| F000CD0A01 | BOSCH |
| FI9069 | SNRA |
| LRS01474 | LUCAS |
| LRS03951 | LUCAS |
| LRS1474 | LUCAS |
| LRS3951 | LUCAS |
| MAV1040 | SIOM |
| MAV1040A | SIOM |
| MRS80064 | MAGNETI MARELLI |
| MSN404 | MAGNETI MARELLI |
| MSN410 | MAGNETI MARELLI |
| MSR654 | MAGNETI MARELLI |
| PRSL147 | 3EFFE |
| QRS1106 | QUINTON HAZELL |
| S0544 | AS-PL |
| S12BH0790A2 | SIDAT |
| SMM110 | AUTOTEAM |
| SMM110A | AUTOTEAM |
| ST01027 | TMI |
| ST02076 | TMI |
| STB8975 | KRAUF |
| STE1125 | KRAUF |
| STR1924 | ELECTROLOG |
| STR8911 | ELECTROLOG |
| STR9002 | ELECTROLOG |
| STR9004 | ELECTROLOG |
| STRL147 | 3EFFE |
| STX200151 | STARDAX |
| TSC1015 | VALEO |
| UD12062S | AS-PL |
Video/Publications
