S0539 - Brand new AS-PL Starter motor

Brand new AS-PL Starter motor
Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 233.05 including GST

NZ$ 202.65 excluding GST
each
S0539
No stock in NZ
Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional
Purchase Qty:

46803965 F000AL0100 S0539 STR50615 UD01255S
Kilowatt1.1 kW
Length (L.1)223 mm
Mount Hole Center - Center (O.1)105 mm
Mount Hole Center - Center (O.2)72 mm
Mount Hole Center - Center (O.3)72 mm
Mount Hole Diameter (C.1)M8x1.25 mm
Mount Hole Diameter (C.2)M8x1.25 mm
Mount Hole Diameter (C.3)M8x1.25 mm
No./Mount holes3 qty
No./Mount holes with thread3 qty
No./Teeth11 qty
Pinion at Rest (B)12 mm
RotationCW
Spigot Diameter (A)64 mm
Unit TypeBOSCH
Voltage12 V
Make Model Type Year
FIAT Albea 1.6 16V 01.1998-
FIAT Brava 1.6 16V 01.1999-12.2002
FIAT Linea 1.8 Flex 01.2010-
FIAT Linea 1.9 16V 01.2008-
FIAT Linea 1.9 16V 01.2009-
FIAT Linea 1.9 Flex 01.2008-12.2010
FIAT Palio 1.6 01.1997-12.2003
FIAT Palio 1.6 01.2001-
FIAT Palio 1.6 16V 01.1998-
FIAT Petra 1.6 16V 01.1998-
FIAT Siena 1.6 16V 01.1998-
FIAT Strada 1.6 01.1998-12.2003
STR50615 46803965 S0539 000F000AL0100 F000AL0100 331422 UD01255S
46803965 F000AL0100 S0539 STR50615 UD01255S
