Associated Numbers
0001413017 0001418014 0031516301 101031 110539 19024008 20401173EL 220255 25-1242 260-46104 33649 550.203.093 6010371 861068 8703 8813320 CS1031 CST10371ES DRS3320 IM414 LRS01197 STR50346 TS-6085 UD11366S UNIT BOM 120-837Specifications
Kilowatt | 3.6 kW |
Length (L.1) | 387 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CLAAS | Dominator 106 | [OM401E] | 01.1980-12.1985 |
CLAAS | Jaguar 680 | [OM421] | 01.1987- |
CLAAS | Jaguar 685 SL | [OM421A] | 01.1987- |
MERCEDES BENZ TRUCKS & BUSES | Engine 11.0 | [421] | 02.1986- |
MERCEDES BENZ TRUCKS & BUSES | Engine 9.6 | [401] | 05.1994- |
NEW HOLLAND | 8080 | [M10Y] | 01.1979-12.1985 |
Reference Information
861068 CGB-11414 101031 TS-6085 A0021517701 220255 25-1242 CS1031 31516301 S0513 1418014 6010371 331183 8703 STR1054 260-46104 STRS916 IM414 DRS3320 1809440 ALTS742 BOM 20401173EL UNIT 120-837 LRS1197 22806 1413017 0001413017 A0031516301 110539 220304 550.203.093 19024008 STR50346 LRS01197 1516653R CST10371ES 21517701 0001418014 8813320 UD11366S 33649Video/Publications
0001413017 0001418014 0031516301 101031 110539 19024008 20401173EL 220255 25-1242 260-46104 33649 550.203.093 6010371 861068 8703 8813320 ALTS742 CGB-11414 CS1031 CST10371ES DRS3320 IM414 LRS01197 LRS1197 STR50346 STRS916 TS-6085 UD11366S UNIT BOM 120-837 220304Add Your Number
