Associated Numbers
20401674OE 254835 254835B 280.501.093 6010476 CST10476GS F002G20524 S0511 UD30036S 0307CC0821N Mahindra 1207334 PIC 280501093 PSH F002G20292 Bosch show STR1250sa Electrolog ARROWHEA BF002G20524 BOSCH MAHINDRA 410-24392Specifications
Kilowatt | 2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 10 mm |
Mount Hole Diameter (C.2) | 10 mm |
Mount Hole Diameter (C.3) | 10 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 2 mm |
Rotation | CW |
Spigot Diameter (A) | 83.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAHINDRA | Bolero 2.5 D | ||
MAHINDRA | Scorpio 2.6 CRDe |
Reference Information
UD30036S 254835B CST10476GS F002G20524 280.501.093 S0511 0307CC0821N STRS446 000F002G20524 20401674OE 6010476 STR1250 254835Video/Publications
20401674OE 254835 254835B 280.501.093 6010476 CST10476GS F002G20524 S0511 STRS446 UD30036SAdd Your Number
