Associated Numbers
0001108428 0001108429 0986024130 114869 12202 20401244BN 20401244OE 25-4076 255046 255046B 30364N 3087 570.555.114 6010442 8200741476 8200741476B 8214332 88214332 AEY2404 BOS0001108428 CS1509 CST10442 CST10442AS CST10442ES CST10442GS CST10442OS CST10442RS DRS0232 EAA-141321 LRS02404 STR50655 UD01603S UD11981SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 214 mm |
Mount Hole Center - Center (O.1) | 74 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 93.5 mm |
Mount Hole Center - Center (O.4) | 22 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
Mount Hole Diameter (C.4) | M10x1.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | -1 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Grand Scenic 1.9 DCi | [F9Q870] | 02.2009- |
RENAULT | Grand Scenic 1.9 DCi | [F9Q872] | 02.2009- |
RENAULT | Megane 1.9 DCi | [F9Q870] | 05.2009- |
RENAULT | Megane 1.9 DCi | [F9Q870] | 06.2009- |
RENAULT | Megane 1.9 DCi | [F9Q870] | 11.2008- |
RENAULT | Megane 1.9 DCi | [F9Q872] | 05.2009- |
RENAULT | Megane 1.9 DCi | [F9Q872] | 06.2009- |
RENAULT | Megane 1.9 DCi | [F9Q872] | 11.2008- |
RENAULT | Megane CC 1.9 DCi | [F9Q870] | 06.2010- |
RENAULT | Scenic 1.9 DCi | [F9Q870] | 02.2009- |
RENAULT | Scenic 1.9 DCi | [F9Q872] | 02.2009- |
Reference Information
986024130 CST10442ES 3087 114869 STRS899 STR50655 0001108429 570.555.114 0001108428 5010523 8200741476B LRS2404 UD01603S 20401244BN STR1503 BOS0001108428 8200741476 12202 20401244OE ANM12452X 7711497369 1108429 1108428 CST10442GS UD11981S CST10442OS AEY2404 255046B EAA-141321 S12BH0688A2 RNL108429 30364N DRS0232 S0497 25-4076 CS1509 330933 000986024130 88214332 CST10442RS 220882 RNL2413 S12BH0688 8214332 255046 6010442 CST10442 CST10442AS LRS02404Video/Publications
0001108428 0001108429 0986024130 114869 12202 20401244BN 20401244OE 25-4076 255046 255046B 30364N 3087 570.555.114 6010442 8200741476 8200741476B 8214332 88214332 AEY2404 BOS0001108428 CS1509 CST10442 CST10442AS CST10442ES CST10442GS CST10442OS CST10442RS DRS0232 EAA-141321 LRS02404 LRS2404 RNL108429 RNL2413 S0497 STR50655 STRS899 UD01603S UD11981S 220882Add Your Number
