Associated Numbers
0001110061 0001110062 02B911023C 02B911023CX 0986016190 103412 10598 112167 11718 11805 17231N 17750N 20401101BN 20401101OE 20401112BN 20500964 22.0597 22.0598 25-1311 300.512.103 3812 42016990 455628 6010101 6010211 8016190 8212695 88212695 8EA726222-001 9141319 943241009010 944280161900 AES9164 CS598 CST10101AS CST10101GS CST10211 CST10211AS CST10211ES CST10211GS CST10211OS CST10211RS DRS6190 EAA-151884 LRS00964 RAS37201 S1046B SS349 SS359 STR50004 STR50619 UD90007S WS37201 17231RSpecifications
Kilowatt | 1.8 kW |
Length (L.1) | 245 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Center - Center (O.2) | 107 mm |
Mount Hole Center - Center (O.3) | 102 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
Mount Hole Diameter (C.3) | 9 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 53 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Eurovan 2.8 Camper | [AES] | 01.1997-01.1998 |
VW | Multivan 2.5 | [AET] | 08.1996-04.2003 |
VW | Transporter 1.9 Diesel | [1X] | 09.1990-12.1995 |
VW | Transporter 1.9 Diesel T4 | [1X] | 07.1990-12.1995 |
VW | Transporter 1.9 Diesel T4 | [1X] | 09.1990-12.1995 |
VW | Transporter 1.9 TD T4 | [ABL] | 10.1992-04.2003 |
VW | Transporter 2.4 Diesel Syncro | [AAB] | 10.1992-09.1998 |
VW | Transporter 2.5 | [AAF] | 11.1990-03.2004 |
VW | Transporter 2.5 | [AAF] | 11.1990-04.2003 |
VW | Transporter 2.5 | [ACU] | 11.1990-03.2004 |
VW | Transporter 2.5 | [ACU] | 11.1990-04.2003 |
VW | Transporter 2.5 | [AEN] | 11.1990-03.2004 |
VW | Transporter 2.5 | [AEN] | 11.1990-04.2003 |
VW | Transporter 2.5 Syncro | [AAF] | 10.1992-03.2004 |
VW | Transporter 2.5 Syncro | [AAF] | 10.1992-04.2003 |
VW | Transporter 2.5 Syncro | [AAF] | 11.1992-04.2003 |
VW | Transporter 2.5 Syncro | [ACU] | 10.1992-03.2004 |
VW | Transporter 2.5 Syncro | [ACU] | 10.1992-04.2003 |
VW | Transporter 2.5 Syncro | [ACU] | 11.1992-04.2003 |
VW | Transporter 2.5 TDi | [ACV] | 09.1995-04.2003 |
Reference Information
112167 CST10211GS S12BH0622A2 UD90007S 986016190 STR50619 20401101OE 5010274 CST10101AS CST10211OS SS359 220085 455628 6010211 17750N 20401101BN 300.512.103 STR10251 SS349 000986016190 88212695 8212695 9.4428E+11 02B911023LX 2B911023C 9141319 STR50004 CST10101GS STRS720 11718 103412 22.0597 22.0598 1110062 1110061 6010101 WS37201 1516782R LRS00964 EAA-151884 CST10211ES 02B911023CX 02B911023J ANM18410X 02B911023N 02B911023L STM523 LRS964 02B911023B 02B911023C 11805 17231R 02B911023D 0001110061 DRS6190 0001110062 17231N 8016190 AES9164 CST10211 S0495 028911023C 3812 STA0049R 02B911023FX 9.43241E+11 RAS37201 CST10211RS 8EA726222-001 42016990 CS598 25-1311 2B911023CX 20401112BN CST10211ASVideo/Publications
0001110061 0001110062 02B911023C 02B911023CX 0986016190 103412 112167 11718 11805 17231N 17231R 17750N 20401101BN 20401101OE 20401112BN 22.0597 22.0598 25-1311 300.512.103 3812 42016990 455628 6010101 6010211 8016190 8212695 88212695 8EA726222-001 9141319 943241009010 944280161900 AES9164 CS598 CST10101AS CST10101GS CST10211 CST10211AS CST10211ES CST10211GS CST10211OS CST10211RS DRS6190 EAA-151884 LRS00964 LRS964 RAS37201 S0495 SS349 SS359 STR50004 STR50619 STRS720 UD90007S WS37201 220085Add Your Number
