Associated Numbers
0001147404 0001147405 25-4237 254625B 278906600 3212 550.543.102 A2789060600 DRS0728 LRS02565 UD802978(BOSCH)S UNIT BOM 120-6532Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 248 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 28 mm |
Rotation | CW |
Spigot Diameter (A) | 60 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | CL 500 4.7 | (216)[M278.920] | 01.2010- |
MERCEDES BENZ | CL 63 5.5 AMG | (216)[M157.980] | 01.2010- |
MERCEDES BENZ | CLS 500 4.7 | (218)[M278.922] | 01.2011- |
MERCEDES BENZ | CLS 500 4.7 4-Matic | (218)[M278.922] | 01.2011- |
MERCEDES BENZ | CLS 63 5.5 AMG | (218)[M157.98.] | 01.2011- |
MERCEDES BENZ | E 500 4.7 | (207)[M278.922] | 01.2011- |
MERCEDES BENZ | E 500 4.7 | (212)[M278.922] | 01.2011- |
MERCEDES BENZ | E 550 4.7 | (207)[M278.922] | 01.2011- |
MERCEDES BENZ | E 63 5.5 AMG | (212)[M157.981] | 01.2011- |
MERCEDES BENZ | S 500 4.7 Cgi | (221)[M278.932] | 01.2011- |
MERCEDES BENZ | S 500 4.7 CGi 4-Matic | (221)[M278.932] | 01.2011- |
MERCEDES BENZ | S 63 5.5 AMG | (221)[M157.980] | 01.2011- |
MERCEDES BENZ | SL 500 4.7 | (231)[M278.927] | 01.2012- |
MERCEDES BENZ | SL 63 5.5 AMG | (231)[M157.983] | 01.2012- |
MERCEDES BENZ | SLK55 5.5 AMG | (172)[M152.980] | 01.2012- |
Reference Information
220954 0001986S00855 A2789060600 A2789060400 1147404 CST10550GS 1147405 6010550 25-4237 3212 CST10550AS 2789060400 2789060600 A27890606000080 20401055OE BOM STR1840 UNIT 254625B UD802978(BOSCH)S 20401055BN A2789061500 A278906060080 DRS0728 1986S00855 120-6532 0001147405 0001147404 LRS02565 278906600 550.543.102 2789061500 2.78906E+13 LRS2565 2.78906E+11 6010550.1Video/Publications
0001147404 0001147405 25-4237 254625B 278906600 3212 550.543.102 A2789060600 DRS0728 LRS02565 LRS2565 UD802978(BOSCH)S UNIT BOM 120-6532 220954Add Your Number
