Associated Numbers
0001107448 0001107449 0001107530 0001107531 063280074010 0986021530 101450 101450D 114886 190.900.092 20401934OE 22.1450 220654 25-4062 28100-0T030 28100-0T030-C 28100-0T030-F 28100-0T060 33291N 428000-5830 600000170170 6010439 8021530 8214085 88212406 88214085 8EA738258-811 9733 AEY2390 BOS0001107530 CS1450 CST10439 CST10439AS CST10439ES CST10439GS CST10439OS CST10439RS DENDSN947 DRS0674 DRT1530 DSN947 J5212131 LRS02390 NEY2390 S0451 SG1079 STB1450 STN1450 STR50284 UD01367S UD13762SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 200 mm |
Mount Hole Center - Center (O.1) | 123 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Avensis Estate 1.6 | [1ZR-FAE] | 02.2009- |
TOYOTA | Avensis Estate 1.8 | [2ZR-FAE] | 02.2009- |
TOYOTA | Avensis Estate 2.0 | [3ZR-FAE] | 02.2009- |
TOYOTA | Avensis Estate 2.0 | [3ZR-FE] | 02.2009- |
TOYOTA | Avensis Saloon 1.6 | [1ZR-FAE] | 11.2008- |
TOYOTA | Avensis Saloon 1.8 | [2ZR-FAE] | 11.2008- |
TOYOTA | Avensis Saloon 2.0 | [3ZR-FAE] | 11.2008- |
TOYOTA | Avensis Saloon 2.0 | [3ZR-FE] | 11.2008- |
TOYOTA | Verso 1.6 | [1ZR-FAE] | 04.2009- |
TOYOTA | Verso 1.8 | [2ZR-FAE] | 04.2009- |
Reference Information
UD13762S 8EA738258-811 CST10439RS 88214085 101450D CST10439 STR1694 28100-0T330 336508 28100-0T050 8214085 CS1450 CST10439AS 428000-5830 2810037020 63280074010 CST10439ES 1107531 28100-37031 28100-37032 0001107531 0001107530 1107530 8021530 28100-0T030-F 28100-0T060 LRS02390 28100-37030 STRS603 RNL2153 20401934OE SG1079 STR50284 28100-0T030-84 88212406 0001107449 BOS0001107530 0001107448 190.900.092 STM1323 DSN947 28100-37020 28100-37021 6E+11 101450 2810037032 33291N 114886 28100-0T030 STB1450 220654 DRT1530 000986021530 DRS0674 LRS2390 STN1450 CST10439GS 28100-0T030-C J5212131 S0451 S12BH0168A2 1107448 1107449 CST10439OS 6010439 9733 2810037021 22.145 DENDSN947 ANM23750X UD01367S 986021530 25-4062 NEY2390 2810037030 2810037031 AEY2390Video/Publications
0001107448 0001107449 0001107530 0001107531 063280074010 0986021530 101450 101450D 114886 190.900.092 20401934OE 22.1450 220654 25-4062 28100-0T030 28100-0T030-C 28100-0T030-F 28100-0T060 33291N 428000-5830 600000170170 6010439 8021530 8214085 88212406 88214085 8EA738258-811 9733 AEY2390 BOS0001107530 CS1450 CST10439 CST10439AS CST10439ES CST10439GS CST10439OS CST10439RS DENDSN947 DRS0674 DRT1530 J5212131 LRS02390 LRS2390 NEY2390 RNL2153 S0451 SG1079 STB1450 STN1450 STR50284 STRS603 UD01367S UD13762SAdd Your Number
