- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
0001410015 0001410016 0001410041 0001417017 0001417036 0011513901 0031516601 0090000 0100000 0120000 10195 110531 16372N 19024136 20401346BN 20401346EL 28.3004 2998007 45-0030 6010643 6220000 8594 860667GB 88.26201-6200 88.26201-9200 A0011513901 A0031516601 CST10643AS CST10643ES DRS1440 F042002123 LRS00823 R22.10 R22.12 UD00248S UD00256S
| Kilowatt | 6.6 kW |
| Length (L.1) | 422 mm |
| No./Mount holes | 0 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 46 mm |
| Rotation | CW |
| Spiggot Diameter (A) | 72 mm |
| Voltage | 24 V |
| ATLAS COPCO | 335 Air Compressor | [KHD F6L514] | 01.1969-12.1979 |
| ATLAS COPCO | PRH425 | [KHD F8L714] | 01.1971-12.1986 |
| MAN | 14.192 | [D2855BYUL] | 01.1972-12.1976 |
| MAN | 16.32 | [D3256BTXUL] | 01.1972-12.1977 |
| MAN | 19.32 | [D3256BTXUL] | 01.1977-12.1979 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.916] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.979] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.980] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.981] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.984] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.985] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.986] | 05.1969-12.1974 |
| MERCEDES BENZ TRUCKS & BUSES | O 317 10.8 | [OM346.911] | 01.1966-01.1976 |
| MERCEDES BENZ TRUCKS & BUSES | O 317 10.8 | [OM346.918] | 01.1966-01.1976 |
220316
220338
8594
10195
0001410015
0001410016
16372N
0100000
0120000
6220000
0001417017
CST10643AS
0001410041
19024136
0001417036
CST10643ES
LRS823
88.26201-9200
DRS1440
STRS718
20401346EL
0011513901
110531
2998007
A0031516601
F042002123
45-0030
860667GB
28.3004
MAV126430
20401346BN
88.26201-6200
0090000
220294
A0011513901
R22.12
LRS00823
UD00248S
6010643
R22.10
0031516601
UD00256S
0001410015 0001410016 0001410041 0001417017 0001417036 0011513901 0031516601 0090000 0100000 0120000 10195 110531 16372N 19024136 20401346BN 20401346EL 28.3004 2998007 45-0030 6010643 6220000 8594 860667GB 88.26201-6200 88.26201-9200 A0011513901 A0031516601 CST10643AS CST10643ES DRS1440 F042002123 LRS00823 LRS823 MAV126430 R22.10 R22.12 STRS718 UD00248S UD00256S 220294 220316 220338
