Associated Numbers
0001417013 11.139.085 19024057 20401146EL 6010641 AZK5437 CST10641ES IS9076 UD00246S UNIT BOM 920-1309Specifications
Insulated Earth | Yes |
Kilowatt | 6.6 kW |
Length (L.1) | 407 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 40 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BAREIROS | B Turbo 300 11.9 | [BS36] | 01.1971-06.1978 |
BAREIROS | TB Turbo 300 11.9 | [BS36] | 01.1971-05.1978 |
BAREIROS | Turbo 300 12.0 | [BS36] | 01.1971-05.1978 |
BAREIROS | Turbo 300 12.0 | [BS36] | 11.1973-05.1983 |
RENAULT | 3464 Turbo 300 12.0 | [BS36] | 05.1983-03.1984 |
RENAULT | 3582 Turbo 300 12.0 | [BS36] | 05.1983-01.1985 |
RENAULT | 3784 Turbo 300 12.0 | [BS36] | 05.1983-01.1985 |
Reference Information
11.139.059 STRE122 UD16632S 6010641.3 72736136 STB1687 MAV126410 CST10641AS 477 20401146BN 920-1309 0001417013 30000 19024057 1411001 AZK5528 STR79515 IS9076 BOM 571.009.123 UNIT MS 11.139.085 CST10641ES 9125050 72736105 331102 1417013 MS508 AZK5437 0001411001 6010641 508 R22-30 20401146EL UD00246S STR79489Video/Publications
0001411001 0001417013 030000.0 11.139.059 11.139.085 19024057 20401146BN 20401146EL 571.009.123 6010641.0 6010641.3 72736105 72736136 9125050 AZK5437 AZK5528 CST10641AS CST10641ES IS9076 MAV126410 MS 477 MS 508 MS508 R22-30 STB1687 STRE122 UD00246S UD16632S UNIT BOM 920-1309Add Your Number
