Associated Numbers
0001416066 11.139.123 19024105 5195100500100 AZK5472 IS9110 UD00239S UNIT BOM 920-1294Specifications
Kilowatt | 5.4 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 126.5 mm |
Mount Hole Center - Center (O.2) | 126.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
STEYR | 11 HU 200 11.0 | [9FUA] | 06.1984- |
STEYR | 11 HU 250 11.0 | [9FUA] | 01.1984- |
STEYR | 11 HUA 280 11.0 | [9FUA] | 06.1984- |
STEYR | 11 HUA 280 11.0 | [9FUA] | 10.1987- |
STEYR | 11 HUA 280 11.0 | [9FUA] | 12.1986- |
STEYR | 18 HUA 280 11.0 | [9FUA] | 07.1987- |
Reference Information
BOM 11.139.123 260-46240 UNIT 5.1951E+12 72736209 MS 920-1294 MS581 AZK5472 581 1416066 19024105 0001416066 UD16938S UD00239S STR79548 S0441 IS9110Video/Publications
0001416066 11.139.123 19024105 260-46240 5195100500100 72736209 AZK5472 IS9110 MS 581 MS581 S0441 UD00239S UD16938S UNIT BOM 920-1294Add Your Number
