Associated Numbers
0001416051 11.139.082 19024045 AZK5436 IS9073 UD00230S UNIT BOM 920-1286Specifications
Insulated Earth | Yes |
Kilowatt | 5.4 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
Pinion at Rest (B) | 39.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BAREIROS | B Turbo 300 11.9 | 01.1971-06.1978 | |
BAREIROS | Turbo 300 12.0 | 01.1971-05.1978 | |
RENAULT | 2626 Turbo 300 12.0 | 05.1983-01.1985 | |
RENAULT | 2626 Turbo 350 12.0 | 05.1983-02.1985 | |
RENAULT | 270.20 12.0 | 02.1985-08.1986 | |
RENAULT | 270.26 12.0 | 02.1985-08.1986 | |
RENAULT | 270.34 12.0 | 04.1984-08.1986 | |
RENAULT | 270.35 12.0 | 02.1985-08.1986 | |
RENAULT | 270.38 12.0 | 04.1985-08.1986 | |
RENAULT | 270 T 12.0 | 03.1984-12.1985 | |
RENAULT | 270 T 12.0 | 04.1985-08.1986 | |
RENAULT | 300 12.0 | 05.1983-08.1986 | |
RENAULT | 3064 12.0 | 05.1983-02.1985 | |
RENAULT | 32012 | 09.1986-11.1987 | |
RENAULT | 32012.0 | 09.1986-11.1987 | |
RENAULT | 320.20 12.0 | 10.1984-12.1985 | |
RENAULT | 320.26 12.0 | 11.1984-12.1985 | |
RENAULT | 320.34 12.0 | 09.1984-12.1985 | |
RENAULT | 320.35 12.0 | 05.1984-12.1985 | |
RENAULT | 320.37 12.0 | 04.1985-12.1985 | |
RENAULT | 320.37 12.0 | 10.1984-12.1985 | |
RENAULT | 320.38 12.0 | 04.1985-08.1986 | |
RENAULT | 320.38 12.0 | 04.1985-12.1985 | |
RENAULT | 320 T 12.0 | 01.1985-12.1985 | |
RENAULT | 320 T 12.0 | 03.1984-08.1986 | |
RENAULT | 340.20 12.0 | 01.1986-11.1988 | |
RENAULT | 340.26 12.0 | 01.1986-11.1988 | |
RENAULT | 340.35 12.0 | 01.1986-11.1988 | |
RENAULT | 340.37 12.0 | 01.1986-11.1988 | |
RENAULT | 340.38 12.0 | 01.1986-11.1988 | |
RENAULT | 340 T 12.0 | 01.1986-11.1988 | |
RENAULT | 3464 Turbo 300 12.0 | 05.1983-03.1984 | |
RENAULT | 3582 Turbo 300 12.0 | 05.1983-01.1985 | |
RENAULT | 3582 Turbo 350 12.0 | 05.1983-02.1985 | |
RENAULT | 3784 Turbo 300 12.0 | 05.1983-02.1985 | |
RENAULT | 38 TR Turbo 355 12.0 | 05.1983-12.1984 |
Reference Information
BOM 920-1286 IS9073 UD00230S UNIT STR10286 MS CGB-11551 11.139.082 STRJ480 AZK5436 514 19024045 1416051 STR79512 0001416051Video/Publications
0001416051 11.139.082 19024045 AZK5436 CGB-11551 IS9073 MS 514 STRJ480 UD00230S UNIT BOM 920-1286Add Your Number
