Associated Numbers
0001416049 10565 11.139.047 19024043 860677 AZK5407 IS9041 UD00229S UNIT BOM 900-101Specifications
Insulated Earth | Yes |
Kilowatt | 5.4 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 91 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
PEGASO | 5117 10.2 | [9100.56] | 01.1984- |
Reference Information
IS9041 STR79483 11.139.047 BOM UNIT MS 494 1416049 0001416049 UD00229S 860677 AZK5407 19024043 900-101 10565Video/Publications
0001416049 10565 11.139.047 19024043 860677 AZK5407 IS9041 MS 494 UD00229S UNIT BOM 900-101Add Your Number
