Associated Numbers
0001121010 0001121011 02B911023F 101176 113677 11939 17231N 17750N 20401723BN 20401723OE 22.1176 22.1176M 25-2451 3025 33031N 443115141319 6010327 8018470 8212297 88212297 AES2243 CS1176 CST10327AS CST10327GS DRS8470 EAA-121589 LRT00243 SS504Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 211 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Center - Center (O.2) | 102 mm |
Mount Hole Center - Center (O.3) | 106 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
Mount Hole Diameter (C.3) | 9 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 52.5 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Multivan 2.0 | [AXA] | 04.2003- |
VW | Transporter 2.0 | [AAC] | 07.1990-03.2004 |
VW | Transporter 2.0 | [AAC] | 07.1990-04.2003 |
VW | Transporter 2.0 | [AAC] | 09.1990-04.2003 |
Reference Information
4.43115E+11 22.1176 113677 101176 LRT00243 33031N STM523 02B911023B 25-2451 CS1176 02B911023F MAV123270 1121010 1121011 17231N DRS8470 8018470 17750N ANM10690X STRL769 1516781R SS504 02B911023FX STR1323 02B911023BX 88212297 20401723OE CST10327GS EAA-121589 8212297 CST10327AS S0401 1516679R AES2243 11939 3025 0001121010 0001121011 22.1176M 20401723BN 6010327Video/Publications
0001121010 0001121011 02B911023F 101176 113677 11939 17231N 17750N 20401723BN 20401723OE 22.1176 22.1176M 25-2451 3025 33031N 443115141319 6010327 8018470 8212297 88212297 AES2243 CS1176 CST10327AS CST10327GS DRS8470 EAA-121589 LRT00243 MAV123270 S0401 SS504 STRL769Add Your Number
