Associated Numbers
0001108061 0001108089 0001311105 0001311315 10135 1398702 26-0239 3523302 464316 5001600 DRS0660 LRS00388Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 242 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 4 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | 260 2.8 V6 | B28..] | 01.1975-12.1984 |
VOLVO | 760 2.8 V6 | [B28..] | 01.1982-1986 |
VOLVO | 760 2.8 V6 | [B280E] | 01.1986-12.1991 |
VOLVO | 760 2.8 V6 | [B280F] | 01.1986-12.1991 |
VOLVO | 780 2.8 V6 | [B280E] | 01.1986-12.1991 |
VOLVO | 780 2.8 V6 | [B280F] | 01.1986-12.1991 |
Reference Information
STR1456 17406N PRSF098 330287 1398702 0001311315 5001600 3523302 1311105 7910245613 580211 LRS388 10135 1108089 0001108089 464316 0001108061 1108061 0001311105 580209 LRS00388 1311315 DRS0660 STRF098 26-0239Video/Publications
0001108061 0001108089 0001311105 0001311315 10135 1398702 26-0239 3523302 464316 5001600 DRS0660 LRS00388 LRS388 STRF098Add Your Number
