Associated Numbers
0001417062 19024083 5010149808 5010511394Specifications
Kilowatt | 6.6 kW |
Length (L.1) | 407 mm |
Mount Hole Center - Center (O.1) | 90.5 mm |
Mount Hole Center - Center (O.2) | 90.5 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 40 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | 280 6x6 12.0 | [MIDS06.35.40D] | 04.1986-10.1992 |
RENAULT | 320 12.0 | [MIDR06.35.40M3] | 10.1992- |
RENAULT | 340 12.0 | [MIDR06.35.40G] | 02.1988-10.1991 |
RENAULT | 340 6x6 12.0 | [MIDR06.35.40G] | 05.1988-10.1992 |
RENAULT | 350 11.2 | [MIDR06.35.40G] | 04.1991-10.1992 |
RENAULT | 350 6x6 12.0 | [MIDR06.35.40G] | 05.1990-01.1993 |
RENAULT | 380 12.0 | [MIDR06.35.40H] | 05.1991-10.1992 |
RENAULT | 380T 12.0 | [MIDR06.35.40H] | 01.1990-10.1992 |
Reference Information
11.139.136 BOM UNIT STR79563 5010149808 260-47288 STB7620 UD16642S 72736145 920-1329 AZK5483 STR50555 MS517 1417062 5010511394 IS9123 19024083 0001417062Video/Publications
0001417062 11.139.136 19024083 260-47288 5010149808 5010511394 72736145 AZK5483 IS9123 MS517 STB7620 STR50555 UD16642S UNIT BOM 920-1329Add Your Number
