Associated Numbers
0001417024 01174647 10384 1173432 1174647 19024064 20401797BN 6010797 CST10797AS IS9079 UNIT BOM 120-835Specifications
Kilowatt | 6.6 kW |
Length (L.1) | 406 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 88.5 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DEUTZ-FAHR | Various Models | ||
KHD | Various Models | ||
MAGIRUS-DEUTZ | Various Models |
Reference Information
BOM 120-835 CST10797AS UNIT STR1322 MS 1417024 1174647 530 B941506 1174645 0001417024 STR79519 10384 1173432 19024064 STR79520 IS9079 6010797 20401797BNVideo/Publications
0001417024 01174647 10384 1173432 19024064 20401797BN 6010797 CST10797AS IS9079 MS 530 UNIT BOM 120-835Add Your Number
