- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0001363101 0001363111 0986011160 0986011161 10231M 11.130.146 11.130.216 110517 12080 18030N 18031N 20401637BN 20404006OE 20500839 22.0231 33345 45-0345 455520 4691200 4744841 4752403 4807377 501.001.093 6010736 6030600 63217201 63217225 63217226 6706931 77080561 860111Z 861049 8651 8811160 88212843 8EA726030-001 AZJ3520 AZJ3542 CS231 CST10736AS CST30600GS DRS1160 EAA-121209 GS363111-A GS363111B-R IS0216 LRS00839 MT72A MT72AA MT72AB S0317 STR22005Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 294 mm |
Mount Hole Center - Center (O.1) | 147 mm |
Mount Hole Center - Center (O.2) | 104 mm |
Mount Hole Center - Center (O.3) | 104 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | 50-8 3.7 | [8040.04.200] | 01.1983-12.1986 |
IVECO | 50-9 3.9 | [8040.05.230] | 01.1987-03.1991 |
IVECO | 60-11 3.9 | [8040.25.230] | 01.1987-03.1991 |
IVECO | 60-8 3.7 | [8040.04.200] | 11.1979-12.1981 |
IVECO | 60-8 3.7 | [8040.04.200] | 11.1979-12.1982 |
IVECO | 60-8 3.7 | [8040.04.200] | 11.1979-12.1983 |
IVECO | 60-9 3.9 | [8040.05.200] | 09.1988-12.1992 |
IVECO | 60 E 10 4.0 | [8040.25B.4200LTC] | 01.1991-08.1996 |
IVECO | 60 E 12 4.0 | [8040.25X.4000TC] | 01.1991-12.1996 |
IVECO | 60 E 14 4.0 | [8040.45.4000TCA] | 01.1991-12.1996 |
IVECO | 65-12 3.9 | [8040.25.200] | 01.1987-03.1991 |
IVECO | 65-9 3.9 | [8040.05.230] | 01.1987-03.1991 |
IVECO | 65 E 10 4.0 | [8040.25B.4200LTC] | 01.1991-12.1996 |
IVECO | 65 E 12 4.0 | [8040.25X.4000TC] | 01.1991-02.2000 |
IVECO | 65 E 12 4.0 | [8040.25X.4000TC] | 01.1991-12.2000 |
IVECO | 65 E 14 4.0 | [8040.45.4000TCA] | 01.1991-02.2000 |
IVECO | 75 E 12 4.0 | [8040.25X.4000TC] | 01.1991-02.2000 |
IVECO | 75 E 12 4.0 | [8040.25X.4000TC] | 01.1997- |
IVECO | 75 E 14 4.0 | [8040.45.4000TCA] | 01.1991- |
IVECO | 75 E 14 4.0 | [8040.45.4000TCA] | 01.1997- |
IVECO | 75 E 14 4.0 | [8040.45.4180TCA] | 01.1991- |
IVECO | 75 E 14 4.0 | [8040.45.4180TCA] | 01.1997- |
IVECO | 79-12 3.9 | [8040.25.200] | 01.1987-03.1991 |
IVECO | 79-12 3.9 | [8040.25.220] | 01.1987-03.1991 |
IVECO | 8041 3.7 | [8041.04..] | 07.1983- |
IVECO | 8041 3.9 | [8041.05..] | 06.1986- |
Reference Information
8651 4744841 77080561 10231M 8EA726030-001 GS363111-A 77080560 CST10736AS ANM13380X PRSL808 S0317 1516715R 42498142 20500839 STRL022 11.130.216 1363101 501.001.093 20404006OE 501.001.093.260 CST30600GS PRSL022 AZJ3542 6010736 63217201 77050561 22.0231 MS STRL808 4744811 9.43202E+11 S24BH0157A2 LRS839 12080 MS448 4706931 6030600.4 19024242 GS363111B-R STR79004 8811160 6030600.1 88212843 LRS00839 92900518 92900352 8EA012586-061 20401637BN 504072485 986011161 986011160 000986011160 45-0345 000986011161 STR22005 220262 6706931 CST30600OS 0001363111 MT72A 455520 63217226 MAV2130 STR1446 6030600 63217225 504038038 AZJ3520 DRS1160 ALTS647 CST30600AS IS0216 110517 18031N 501.001.093.215 33345 929162 42498230 389 11.130.146 501.001.093.211 004691200X CS231 EAA-121209 4752403 0001363101 4807377 501.001.093.010 1363111 4691200 MT72AA MT72AB 2997051Video/Publications
0001363101 0001363111 0986011160 0986011161 10231M 11.130.146 11.130.216 110517 12080 18030N 18031N 20401637BN 20404006OE 20500839 22.0231 33345 45-0345 455520 4691200 4706931 4744841 4752403 4807377 501.001.093 6010736 6030600 63217201 63217225 63217226 6706931 77080561 860111Z 861049 8651 8811160 88212843 8EA726030-001 ALTS647 AZJ3520 AZJ3542 CS231 CST10736AS CST30600GS DRS1160 EAA-121209 GS363111-A GS363111B-R IS0216 LRS00839 LRS839 MAV2130 MS 389 MT72A MT72AA MT72AB S0317 STR22005 STRL022 220262Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
