S0296 - Brand new AS-PL Starter motor

Name: Brand new AS-PL Starter motor
Brand: AS-PL
SKU: S0296
Price: 680.45 NZD
Availability: InStock

Brand new AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

BOSCH

Price:

NZ$ 680.45 including GST

NZ$ 591.70 excluding GST

UOM:

each

Product Code:

S0296

Quantity In Stock:

No stock in NZ

Availability:

Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications
Add Your Number

0001230008 0001230018 114195 20401183BN 254366 35259600 6010381 6572N 8200326 905720100079 CST10381AS CST10381GS DRS0362 RE501551 RE507943 RE509856 STR50416

Kilowatt	3 kW
Length (L.1)	315 mm
Mount Hole Center - Center (O.1)	90 mm
Mount Hole Center - Center (O.2)	127 mm
Mount Hole Center - Center (O.3)	90 mm
Mount Hole Diameter (C.1)	11 mm
Mount Hole Diameter (C.2)	11 mm
Mount Hole Diameter (C.3)	11 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	10 qty
No./Teeth (Replaces)	10 qty
Pinion at Rest (B)	48 mm
Rotation	CW
Spigot Diameter (A)	89 mm
Unit Type	BOSCH
Voltage	12 V

Make	Model	Type	Year
JOHN DEERE	Various Models

5010530 88215000 331300 120-6109 RE509856 S12BH0704A2 114195 1230018 6010381 1230008 RE507943 STRS677 CGB-93008 20401183OE 630.505.103.010 RE501551 CST10381AS STR50416 254366 DRS0362 S0296 CST10381GS 6010381.1 20401183BN

0001230008 0001230018 114195 20401183BN 254366 35259600 6010381 6572N 8200326 905720100079 CST10381AS CST10381GS DRS0362 RE501551 RE507943 RE509856 STR50416 STRL700
