Associated Numbers
0001125021 0001125022 0001125051 0001125052 02T911023C 02T911023H 02T911023HX 063721200010 0986018500 101200 101200B 112438 116335 11940 20401561 220212 25-2474 300.542.102 3026 31231N 458586 6010165 8213060 88213060 8EA011610-091 8EA737856-001 943212001010 943253160010 944280185000 AES2221 BOS0001125051 CS1200 CST10165 CST10165AS CST10165ES CST10165GS CST10165OS CST10165RS DRS8500 DS9610 EAA-121157 LRT00221 MQS1200 MRS18500 MSR5360 MSRC1200 SG0017 STB1200 STR50299Specifications
Kilowatt | 2 kW |
Length (L.1) | 235 mm |
Mount Hole Center - Center (O.1) | 112 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 52 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SEAT | Cordoba 1.9 SDi | [ASY] | 09.2002- |
SKODA | Fabia 1.4 TDi | [BNV] | 06.2007- |
SKODA | Fabia 1.9 SDi | [ASY] | 12.1999- |
SKODA | Roomster 1.4 TDi | [BMS] | 09.2006- |
SKODA | Roomster 1.4 TDi | [BNV] | 09.2006- |
SKODA | Roomster 1.9 TDi | [AXR] | 03.2006-05.2006 |
SKODA | Roomster 1.9 TDi | [BLS] | 09.2006- |
SKODA | Roomster 1.9 TDi | [BSW] | 09.2006- |
VW | Fox 1.4 TDi | [BNM] | 04.2005- |
VW | Polo 1.9 SDi | [ASY] | 09.2002- |
VW | Spacefox 1.9 SDi | [ASY] | 09.2007- |
Reference Information
0001125052 1125051 101200B 1125052 DRS8500 2T911023C 0001125051 20401561 02T911023CX 2T911023H STRW411 MRS18500 LRT00221 02T911023H 25-2474 8EA737856-001 9.43253E+11 116335 02T911023C 11940 STR50299 112438 300.542.102 1125021 1125022 0001125021 0001125022 CST10165ES CS1200 MSRC1200 88213060 CST10165AS 9.4428E+11 8EA011610-091 986018500 MQS1200 8213060 MSR5360 DS9610 220212 31231N EAA-121157 2T911023CX STB1200 101200 63721200010 SG0017 CST10165RS CST10165OS 02T911023HX BOS0001125051 CST10165GS MAV121650 STR1569 2T911023HX AES2221 9.43212E+11 6010165 3026 CST10165 LRT221 458586 S12BH0175A2 000986018500Video/Publications
0001125021 0001125022 0001125051 0001125052 02T911023C 02T911023H 02T911023HX 063721200010 0986018500 101200 101200B 112438 116335 11940 20401561 220212 25-2474 300.542.102 3026 31231N 458586 6010165 8213060 88213060 8EA011610-091 8EA737856-001 943212001010 943253160010 944280185000 AES2221 BOS0001125051 CS1200 CST10165 CST10165AS CST10165ES CST10165GS CST10165OS CST10165RS DRS8500 DS9610 EAA-121157 LRT00221 MAV121650 MQS1200 MRS18500 MSR5360 MSRC1200 SG0017 STB1200 STR50299 STRW411Add Your Number
