Associated Numbers
0001109017 11.130.979 112496 254607 5474041 5474046 6010388 CST10388GS STR50198Specifications
Kilowatt | 2 kW |
Length (L.1) | 255 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 74 mm |
Mount Hole Center - Center (O.3) | 74 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | 9 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 14.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FARYMANN | Various Models |
Reference Information
1109017 120-10126 STR1508 CST10388GS 331880 5474046 20401883OE 5474761 5474041 182-30136 S0208 STB2496 STRF271 112496 6010388 254607 11.130.979 0001109017 STR50198Video/Publications
0001109017 11.130.979 112496 120-10126 182-30136 20401883OE 254607 5474041 5474046 6010388.0 CST10388GS S0208 STB2496 STR50198 STRF271Add Your Number
