Associated Numbers
0001126016 101165 20513047 8018380 88213980 DRS8380 DRS8380NSpecifications
Kilowatt | 1.7 kW |
Length (L.1) | 228 mm |
Mount Hole Center - Center (O.1) | 105.5 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | LT 28-35 2.5 TDi | [AHD] | 05.1996-05.1999 |
VW | LT 28-35 2.5 TDi | [APA] | 05.1999-04.2001 |
VW | LT 28-35 2.5 TDi | [BBE] | 05.2001-07.2006 |
VW | LT 28-35 2.5 TDi | [BBF] | 09.2001-10.2001 |
VW | LT 28-46 2.5 TDi | [AHD] | 05.1996-05.1999 |
VW | LT 28-46 2.5 TDi | [APA] | 05.1999-04.2001 |
VW | LT 28-46 2.5 TDi | [BBE] | 09.2001-10.2001 |
VW | LT 28-46 2.5 TDi | [BBF] | 09.2001-10.2001 |
Reference Information
101165 88213980 220581 MAV122810 DRS8380 DRS8380N 1126016 0001126016 20513047 8018380Video/Publications
0001126016 101165 20513047 8018380 88213980 DRS8380 DRS8380N MAV122810 220581Add Your Number
