- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0001230012 0001262030 0001358005 0001359038 0001359056 0001359083 0001359113 0001362023 0001362036 0001367005 0986024080 10718 10718B 11.130.254 11.130.898 11.131.829 111001 19024250 25-0270 25-0275 25-0287 254072 254072K 255527 29619390 60811 60811D 60811K 60811M 63216816 760.001.092 9144820 943216852 AZF4220 AZJ3320 AZJ3557 CS718 DRS3326 GS367005-A IS0254 IS0548 IS0671 LRS00949 LRS01053 MT68R MT68RA S0200 STR50157Specifications
Kilowatt | 3 kW |
Length (L.1) | 316 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAMBORGHINI | 105 Diesel Formula | [1004.4] | 03.1989-12.1999 |
LAMBORGHINI | 1106 5.5 Diesel 2M | [916.6] | 01.1984-12.1999 |
LAMBORGHINI | 115 6.0 Diesel Formula | [1000.6] | 12.1989-12.1999 |
LAMBORGHINI | 1306 5.5 TD DT | [916.6] | 01.1984-12.1999 |
LAMBORGHINI | 1506 6.8 TD | [1106HT] | 01.1984-12.1999 |
LAMBORGHINI | 1706 6.8 TD | [1106] | 01.1984-12.1999 |
LAMBORGHINI | 660 3.1 Diesel | [105.3] | 01.1987-12.1999 |
LAMBORGHINI | 660 F 3.0 Diesel | [1000.3] | 06.1987-12.1999 |
LAMBORGHINI | 775 F 3.0 Diesel Plus | [1000.3] | 05.1991-12.1999 |
LAMBORGHINI | 956 DT 5.5 Diesel | [916.6] | 01.1984-12.1999 |
LAMBORGHINI | 956-2 RM 5.5 Diesel | [916.6] | 01.1984-12.1999 |
LAMBORGHINI | C 664 3.1 Diesel | 06.1987-12.2000 | |
SAME | Explorer 70 4.0 Diesel | 07.1986- | |
SAME | Explorer 80 4.0 Diesel | 07.1986- | |
SAME | Explorer 90 4.0 Diesel | 06.1986- | |
SAME | Frutteto 75 3.0 Diesel | 05.1991- | |
SAME | Laser 110 5.7 Diesel | 01.1988- | |
SAME | Laser 130 6.2 Diesel | 01.1988- | |
SAME | Laser 150 6.2 Diesel | 01.1988- | |
SAME | Solar 60 3.1 Diesel | 06.1986- | |
STEYR | 8110 5.2 | [WD611..] | 07.1984- |
STEYR | 8130 5.2 | [WD611..] | 07.1984- |
Reference Information
29619390 MT68RA 61100090002 0001262029 1262029 20401165OE 296192300 8693R 10718 30800090001 296192900 10718B 20401165BN STB0718 260-23107 6010561.1 5000589041 299392950 1262030 7701019038 111001 5010403 TS-6197 29619560010 0001262030 29619560 760.501.092.010 760.501.092.210 MT68R CST10561GS 296195600 EAA-111295 1516803R 296193900 6010561 CST10561AS 19269N 30800090017 CGB-23326 S0200 STR50662Video/Publications
STR50662 19269N 6010561.1 6010561.0 296195600 20401165OE 20401165BN 760.501.092.210 760.501.092.010 10718B STB0718 EAA-111295 TS-6197 260-23107 8693R CST10561GS CST10561AS 111001 0001262030 0001262029 CGB-23326 S0200Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
