Associated Numbers
0001109260 0001109261 059911023A 059911024F 20401414OE 20401414RC 25-3498 254360 254360B 6010414 AEY2326 CST10414GS CST10414RS LRS02326 STR50514 Bosch show 059911023R VW 059911024 059911024A 059911024AX 059911024FX 059911024G 106150 FARC 11022450 EuroTec 11090131 115938 Cargo 200549102 PSH 253365 Elstock 3074 CEVAM 311245102 DRI 3176 33195 Lester 458877 Valeo 8080266 Friesen 910374 EDR DRS0374 Remy Lucas LRS2326 WAI New Alltech 111-33195 American Power Systems APS33195 Armature G Roy Atelier Dynamo S120-6416 Audi Volkswagen 059-911-023A 059-911-023R 059-911-024A 059-911-024F 059-911-024FX Bepco 80-33195 261 Casco A/S Denmark EGI S-33195 ERA 220636 Electrical Europe Elektrik LES0537 Mondial 70-246-160 Our Part Number # PASCO S-3006416 Select Powerite Automotive Quality Rebuilders 133195 Raw Road Warrior Stratoline TSA 33195N UCP Remanufactured ZorkoSpecifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 251 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| Pinion at Rest (B) | 25 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A8 3.0 TDi Quattro | [ASB] | 08.2003- |
Reference Information
220636 115938 S0191 1109261 059911023A AEY2326 CST10414RS 332247 1109260 MAV123000 20401414RC STR50514 CST10414GS 254360B 6010414 LRS2326 STR1422 059911024AX 059911024F 059911024A 254360 3176 20401414OE 25-3498 0001109260 0001109261 059911023R LRS02326 059911024FXVideo/Publications
0001109260 0001109261 059911023A 059911024F 115938 20401414OE 20401414RC 25-3498 254360 254360B 6010414 AEY2326 CST10414GS CST10414RS LRS02326 LRS2326 MAV123000 S0191 STR50514 220636Add Your Number
