Associated Numbers
0001109267 20401644OE 25-4015 254196 254196B 31510N 35532055F 6010446 CST10446GS STR50233
0001109267 20401644OE 25-4015 254196 254196B 31510N 35532055F 6010446 CST10446GS STR50233
0001109267
0001109267 20401644OE 25-4015 254196 254196B 31510N 35532055F 6010446 CST10446GS STR50233
0001109267 BOSCHList
CST10446GS CASCO
25-4015 ELSTOCK
254196 KUHNER
254196B KUHNER
20401644OE REAL
6010446 SANDO
35532055F VM
31510N WAI / TRANSPO
STR50233 WOODAUTO
0001109254 Bosch
0001109267 Bosch
11090134 EuroTec
114020 Cargo
120665 PIC
12313 EAI
31510 Lester
35532055F VM (STABILIMENTI MEC
500543093 PSH
518100009
8080324F Friesen
910021 EDR
DRS0021 Remy
IS1199 Mahle
LRS02343 Lucas
STR1522sa Electrolog
0001109267 BOSCHList
CST10446GS CASCO
25-4015 ELSTOCK
254196 KUHNER
254196B KUHNER
20401644OE REAL
6010446 SANDO
35532055F VM
31510N WAI / TRANSPO
STR50233 WOODAUTO
0001109254 Bosch
0001109267 Bosch
11090134 EuroTec
114020 Cargo
120665 PIC
12313 EAI
31510 Lester
35532055F VM (STABILIMENTI MEC
500543093 PSH
518100009
8080324F Friesen
910021 EDR
DRS0021 Remy
IS1199 Mahle
LRS02343 Lucas
STR1522sa Electrolog
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 82 mm |
| Mount Hole Center - Center (O.2) | 82 mm |
| Mount Hole Center - Center (O.3) | 116 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | 9 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | -1 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LDV | Maxus 2.5 CDI | 01.2005- | |
| LTI | TX4 2.5 D | 01.2006- | |
| VM | Engine Diesel | [R425 DOHC] | |
| VM | Engine Diesel | [R425DOHC] |
Reference Information
35532055F CST10446GS 1109267 254196 31510N 332266 25-4015 114020 20401644OE 254196B STRL113 S0189 STR50233 6010446Video/Publications
0001109267 114020 20401644OE 25-4015 254196 254196B 31510N 35532055F 6010446 CST10446GS STR50233 STRL113 S0189Add Your Number
