Associated Numbers
0001108043 0001109001 0001109002 031911023 031911023A 031911023AX 031911023X 0986014580 10500 11409 20401402RC 22.0500 25-1182 25-1360 33039R 3642 42014580 436047 6010204 8014580 88213215 8EA726148-001 AES9113 CS500 CST10204RS DRS4580 EAA-121423 LRS00890 SS547 STR50328Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 244 mm |
Mount Hole Center - Center (O.1) | 74.5 mm |
Mount Hole Center - Center (O.2) | 74.5 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | 8 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 14.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SEAT | TeRa 1.3 Diesel | [MN] | 03.1990-12.1994 |
SEAT | TeRa 1.4 Diesel | [1W] | 10.1990-12.1995 |
VW | Polo 1.3 Diesel | [MN] | 08.1986-08.1990 |
VW | Polo 1.4 Diesel | [1W] | 10.1990-09.1994 |
Reference Information
DRS4580 1109002 STR1299 1109001 31911023AX 5010436 CST10204RS S12BH0439A2 31911023A 42014580 031911023A MAV122040 CS500 11409 115540 031911023AX LRS00890 STRL203 25-1182 436047 25-1360 SS547 8014580 31911023X EAA-121423 0001108043 ANM16800X 1108043 8EA726148-001 22.05 31911023 330652 33039R 986014580 220095 20401402RC AES9113 STR50328 031911023X LRS890 STA0216R 0001109001 3642 88213215 0001109002 000986014580 10500 6010204Video/Publications
0001108043 0001109001 0001109002 031911023 031911023A 031911023AX 031911023X 0986014580 10500 11409 115540 20401402RC 22.0500 25-1182 25-1360 33039R 3642 42014580 436047 6010204 8014580 88213215 8EA726148-001 AES9113 CS500 CST10204RS DRS4580 EAA-121423 LRS00890 LRS890 MAV122040 SS547 STR50328 STRL203 220095Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
