Associated Numbers
0001107410 0001107418 0986020900 101289 1149703 11994 1309581 20401404RC 22.1289 25-3250 2S6U11000DA 2S6U11000DB 3120 32708N 4S6911000AA 6010404 8080110 8212761 88212761 8EA738132-001 AEU1289 CS1289 CST10404RS DRT0900 EAA-121293 F004A94410 LRS01700 S0185 SS219 STR50302 32708RSpecifications
Kilowatt | 1.1 kW |
Length (L.1) | 200 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 67 mm |
Mount Hole Center - Center (O.3) | 67 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Fiesta 1.3 | [A9JA] | 11.2001- |
FORD | Fiesta 1.3 | [A9JB] | 11.2001- |
FORD | Fiesta 1.3 | [BAJA] | 11.2001- |
FORD | Ka 1.3 i | [A9A] | 08.2002-06.2003 |
FORD | Ka 1.3 i | [A9B] | 08.2002-06.2003 |
FORD | Ka 1.3 i | [BAA] | 09.1996-10.2002 |
FORD | Ka 1.6 i | [CDB] | 07.2003- |
FORD | Ka 1.6 i | [CDC] | 07.2003- |
FORD | Ka 1.6 Street | [CDRA] | 02.2003- |
FORD | Ka 1.6 Street | [CDRB] | 02.2003- |
FORD | Streetka 1.6 i | 12.2002- |
Reference Information
EAA-121293 RE2S6U-11000-DC DRT0900 20401404BN 5010270 3120 RE2S6U11000DC 4S6911000AA 20401404OE 1149703 DSN3002 000986020900 2S6U11000DC 2S6U11000DB 8EA738132-001 2S6U11000DA 0001107418 LRS01700 94114DB 1107410 0001107410 1564732 CS1289 1309581 20401404RC 1107418 CST10404GS STA0357R 11994 590.534.103.000 88212761 STR1275 986020900 220411 1871851 PRSS261 6010404.2 6010404.1 101289 590.534.103.010 000F004A94410 LRS1700 S12BH0368A2 3S6511000BA F004A94410 AEU1289 STRS261 3N2T11000AB CST10404RS 32708N 114162 STR50302 32708R ANM23120X 6010404 25-3250 CST10404ASVideo/Publications
0001107410 0001107418 0986020900 101289 114162 1149703 11994 1309581 1564732 20401404RC 22.1289 25-3250 2S6U11000DA 2S6U11000DB 3120 32708N 32708R 4S6911000AA 6010404 8080110 8212761 88212761 8EA738132-001 AEU1289 CS1289 CST10404RS DRT0900 EAA-121293 F004A94410 LRS01700 LRS1700 RNL2090 S0185 SS219 STR50302 STRS261 220411Add Your Number
