Associated Numbers
0001125503 0001125504 0001125513 0001125514 069911023H 069911023K 101115 112014 11888 20401555BN 20513055 22.1115 25-2492 32555N 42018380 6010555 88212360 8EA737567-001 AEU1115 CS1115 CST10555AS DRS3809 EAA-121617 LRS01519 SS617 STR50178Specifications
Kilowatt | 2 kW |
Length (L.1) | 234 mm |
Mount Hole Center - Center (O.1) | 50 mm |
Mount Hole Center - Center (O.2) | 93 mm |
Mount Hole Center - Center (O.3) | 105.5 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | 8 mm |
Mount Hole Diameter (C.3) | M12x1.75 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | LT 28-35 2.5 SDi | [AGX] | 07.1996-04.2001 |
VW | LT 40-55 2.5 SDi | [AGX] | 05.1996-04.2001 |
Reference Information
88212360 069911023K SS617 CS1115 AEU1115 DRS3809 ANM16029X STR1459 11888 EAA-121617 069911023HX 32555N 22.1115 1125513 0001125504 1125514 STR50178 6010555 25-2492 0001125503 MAV125550A 8EA737567-001 STRL705 112014 AS1613 CST10555AS 331267 069911023KX 069611023H 20513055 LRS1519 LRS01519 1516661R 101115 STA0399R 069911023H 20401555BN 1125503 1125504 0001125513 S0169 0001125514Video/Publications
0001125503 0001125504 0001125513 0001125514 069911023H 069911023K 101115 112014 11888 20401555BN 20513055 22.1115 25-2492 32555N 42018380 6010555 88212360 8EA737567-001 AEU1115 CS1115 CST10555AS DRS3809 EAA-121617 LRS01519 LRS1519 MAV122960 S0169 SS617 STR50178 STRL705Add Your Number
