Associated Numbers
0001107086 0001107088 0001107433 0001107434 0986018480 0986021060 113271 12042 190.536.112 201230 201230D 201236 20401052 20513001 220675 228000-7580 228000-7581 228000-7583 228000-7590 228000-7591 228000-7593 25-2404 28100-0D030 28100-0D050 28100-0D130 28100-22030 28100-22031 28100-22040 28100-22041 31244N 31244R 458485 6010250 88212742 8EA012526-431 8EA738002-001 943212361010 944280184800 9518 AES2244 BOS0001107433 CST10250 CST10250AS CST10250ES CST10250GS CST10250OS CST10250RS DRS8480 DS9590 DSN921 EAA-121232 EAA-121503 J5212118 JS1236 LRT00244 MRS18480 MSRC1236 NES2244 RAS39591 RNL1848 S0168 SG0986 SS293 SS570 SS612 STM770 STN1236 STR50185Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 210 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 9. 11 qty |
Pinion at Rest (B) | 16 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Avensis 1.6 i 16V | [3ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Avensis 1.8 i 16V | [1ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Celica 1.8 16V TS | [2ZZ-GE] | 08.1999-09.2005 |
TOYOTA | Celica 1.8 VVTi 16V | [1ZZ-FE] | 08.1999-07.2005 |
TOYOTA | Corolla 1.4 | [4ZZ-FE] | 02.2000-01.2002 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-11.2001 |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 01.2002- |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 01.2002-05.2004 |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 08.2002- |
TOYOTA | Corolla 1.6 | [3ZZ-FE] | 02.2000-01.2002 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 02.2000-11.2001 |
TOYOTA | Corolla 1.6 VVTi | [3ZZ-FE] | 01.2002- |
TOYOTA | Corolla 1.6 VVTi | [3ZZ-FE] | 08.2002- |
TOYOTA | Corolla 1.6 VVTi Verso | [3ZZ-FE] | 01.2002-05.2004 |
TOYOTA | Corolla 1.8 i 16V Verso | [1ZZ-FE] | 09.2001-05.2004 |
TOYOTA | Corolla 1.8 i WTL-i TS | [2ZZ-GE] | 01.2002- |
TOYOTA | Corolla 1.8 VVTL-i TS | [2ZZ-GE] | 10.2005- |
TOYOTA | RAV4 1.8 i 16V | [1ZZ-FE] | 08.2000-11.2005 |
Reference Information
CST10250AS 003-T909 1107088 0001107088 000986018480 CST10250GS 220675 LRT00244 201236 28100-0D030 3T909 6010250 9518 2810076130 STA0338R 28100-0D130 8EA012526-431 STM770 JS1236 12042 RNL1848 3T364 STR1188 986018480 281000T110 25-2404 PRSF283 31244N 6010250.1 281000D130 31244R MTT364 PRSS515 281000D030 S12BH0225A2 2810022040 DS9590 2810022041 88212742 DRS8480 STR50185 SG0986 458485 MAV461160 003-T364 190.536.112 MTT909 S0168Video/Publications
0001107088 003-T364 003-T909 0986018480 12042 190.536.112 201236 2280003282 25-2404 2810076130 31244N 31244R 3T364 3T909 458485 88212742 8EA012526-431 9518 DRS8480 DS9590 JS1236 LRT00244 MAV461160 MTT364 MTT909 RNL1848 S0168 SG0986 STM770 STR50185 220675Add Your Number
