Associated Numbers
0001510025 0001510169 0021519201 20401397BN 20401397OE 254311 51.26201-7136 51.26201-7221 6010793 861054 CST10793AS CST10793GS EAA-121441 S0167 STR50244Specifications
Kilowatt | 9 kW |
Length (L.1) | 460 mm |
Mount Hole Center - Center (O.1) | 126.5 mm |
Mount Hole Center - Center (O.2) | 126.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 51 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ TRUCKS & BUSES | OM 424 | [OM 424] | 08.1983- |
MERCEDES BENZ TRUCKS & BUSES | OM 424 | [OM424] | 08.1983- |
Reference Information
861054 A0021519201 6104085 STR1781 CST10793AS 331760 20401397OE EAA-121441 CGB-91025 254311 STRS311 1510169 6010793 20401397BN 51.26201-7136 1510025 0001510169 51.26201-7221 CST10793GS S0167 STR50244 0001510025 21519201Video/Publications
0001510025 0001510169 0021519201 20401397BN 20401397OE 254311 51.26201-7136 51.26201-7221 6010793 861054 CGB-91025 CST10793AS CST10793GS EAA-121441 S0167 STR50244 STRS311Add Your Number
