Associated Numbers
0001218818 0986015920 11481 160.541.092 20417701BN 20417701RC 20568 22.0568 23300-7C625 23300-9C600 23300-D9700 23300-D9701 23300-D9702 23300-Y9700 25-1075 33678 455881 6045107 8015920 8EA726511-001 9000331406 9000331421 9000331424 9000331430 9590 AES1204 CST45107AS CST45107RS DRS3173 EAA-121997 JS568 LRT00104 SS152 SS212 STR22113Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 262 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 9 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Serena 2.0 Diesel | (C23M)[LD20] | 11.1992-09.1994 |
NISSAN | Serena 2.3 Diesel | (C23M)[LD23] | 09.1994-11.2001 |
NISSAN | Vanette 2.0 Diesel | (C22)[LD20-II] | 12.1987-11.1994 |
NISSAN | Vanette Cargo 2.0 Diesel | (C23M)[LD20] | 07.1992-09.1994 |
NISSAN | Vanette Cargo 2.3 Diesel | (C23M)[LD23] | 09.1994-11.2001 |
Reference Information
DRS3173 STR1771 335418 0009000331421 8015920 LRT00104 STRS096 23300-7C600 0009000331424 MAV471070 23300-9C600 0009000331428 23300-D9700 ANM15393X SS152 20417701BN 23300-D9702 22.0568 23300-D9701 9000331406 23300-G9900-EP 220822 5010206 0001218818 0009000331430 23300-D9702-EP 9590 STRS364 CST45107AS 003-D158 STR22113 6045107 160.541.092 CST45107RS 20417701RC 11481 23300D9702EP 9000331430 AES1204 EAA-121997 SS212 23300-7C625 33678 0009000331406 000986015920 MTD158 25-1402 986015920 9000331428 23300-Y9700 455881 8EA726511-001 9000331424 S12BH0570A2 9000331421 1218818 233007C600 3D158 20568 114318 335786 MAV471080 1516974R 23300-G9900 JS568 23300G9900 S0165 25-1075Video/Publications
0001218818 003-D158 0986015920 114318 11481 160.541.092 20417701BN 20417701RC 20568 22.0568 23300-7C625 23300-9C600 23300-D9700 23300-D9701 23300-D9702 23300-Y9700 25-1075 25-1402 33678 3D158 455881 6045107 8015920 8EA726511-001 9000331406 9000331421 9000331424 9000331428 9000331430 9590 AES1204 CST45107AS CST45107RS DRS3173 EAA-121997 JS568 LRT00104 MAV471070 MAV471080 MTD158 S0165 SS152 SS212 STR22113 STRS096 STRS364 220822Add Your Number
