Associated Numbers
00010EA6EE 0001218822 062911023 062911023X 20401083BN 20401083OE 22.3088 22.3088M 25-3265 254148 6010380 6033AB1J00 AEY1710 CST10380AS CST10380GS DRS0044 EAA-121180 LRS01710 RNL218822 SS373 STR50461Specifications
Kilowatt | 2.3 kW |
Length (L.1) | 272 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 103 mm |
Mount Hole Center - Center (O.3) | 146 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | LT 28 2.8 TDi | 01.2003- | |
VW | LT 28-35 2.8 TDi | [AGK] | 07.1997-05.2003 |
VW | LT 28-35 2.8 TDi | [ATA] | 01.1999-01.2002 |
VW | LT 28-35 2.8 TDi | [AUH] | 05.2001-06.2006 |
VW | LT 28-35 2.8 TDi | [BCQ] | 05.2001-06.2006 |
VW | LT 28-46 2.8 TDi | [AGK] | 07.1997-01.2002 |
VW | LT 28-46 2.8 TDi | [ATA] | 01.1999-07.2006 |
VW | LT 28-46 2.8 TDi | [AUH] | 04.2002-07.2006 |
VW | LT 28-46 2.8 TDi | [BCQ] | 04.2002-07.2006 |
VW | LT 35 2.8 TDi | 01.2003- | |
VW | LT 46 2.8 TDi | 01.2002- |
Reference Information
88214286 93278011 00000010EA6EE 5010438 6033AB1J00 BOS0001109417 114304 20401083BN 300.553.093.011 CST10380AS 300.553.093.210 0006033AB1J00 300.553.093.010 9.0572E+11 300.553.093.211 S0153 20401083OE CGB-28820 0001109417 EAA-121180 331204 000986023860 6010380 DRS0044 32710R LRS1710 6010380.1 1218822 STA0360R 0001218822 STRL719 986023860 AEY1710 STM764 STR1637 12090 254148 25-3265 SS373 CST10380GS CGB-53265 22.3088 3111 062911023X 62911023 PRSL719 RNL218822 S12BH0443A2 STB4822 22.3088M ANM12264X STR50461 00010EA6EE 1109417 LRS01710Video/Publications
00010EA6EE 0001218822 062911023 062911023X 20401083BN 20401083OE 22.3088 22.3088M 25-3265 254148 6010380 6033AB1J00 AEY1710 CGB-28820 CST10380AS CST10380GS DRS0044 EAA-121180 LRS01710 LRS1710 RNL218822 S0153 SS373 STR50461 STRL719Add Your Number
