Associated Numbers
0001402055 0001402059 0001402081 0001402083 0001414003 0001414010 0001415002 0001416022 0001416024 0001416047 0001416054 0011514101 0021518501 0031515701 0031516001 03285 04667 0986011550 10194 10194P 110512 20401026BN 20401236BN 20401236EL 22.0194 22201 22626 254021D 254021K 254021L 254021M 256019 33419 33583 349581 359581 45-0091 45-1428 455505 455615 455926 5000080750 5000592182 5000789048 5001014203 5001014215 51.26201-7112 51.26201-9074 551.102.093 551.207.093 6010620 6010632 860653 860657GB 860660GB 8682 8811550 8EA726023-001 A0011514101 A0021518501 A0031515701 A0031516001 CS194 CST10620AS CST10632AS CST10632ES DRS1420 DRS1550 EAA-111401 IM522 LRS00817 LRS00824 LRS00843 STR22038Specifications
Kilowatt | 5.4 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Center - Center (O.2) | 129 mm |
Mount Hole Center - Center (O.3) | 91 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ TRUCKS & BUSES | 1222 11.0 | (MK)[OM441.905](MK)[OM441.913] | 07.1989-08.1994 |
MERCEDES BENZ TRUCKS & BUSES | 1222 11.0 | (MK)[OM441.914] | 09.1989-07.1994 |
MERCEDES BENZ TRUCKS & BUSES | 1222 11.0 | (MK)[OM441.915](MK)[OM441.917](MK)[OM441.923] | 07.1989-08.1994 |
MERCEDES BENZ TRUCKS & BUSES | 1222 11.0 | (MK)[OM441.926] | 09.1989-07.1994 |
MERCEDES BENZ TRUCKS & BUSES | 408 3.8 Diesel | (T2/L)[OM314.948] | 01.1970-01.1973 |
MERCEDES BENZ TRUCKS & BUSES | 508 3.8 Diesel | (T2/L)[OM314.946](T2/L)[OM314.948] | 02.1973-12.1988 |
MERCEDES BENZ TRUCKS & BUSES | 608 3.8 | (LP)[OM314.910](LP)[OM314.944] | 10.1969-01.1973 |
MERCEDES BENZ TRUCKS & BUSES | 608 3.8 | (T2/L)[OM314.948](T2/L)[OM314.967] | 09.1982-12.1988 |
MERCEDES BENZ TRUCKS & BUSES | 808 3.8 | (LP)[OM314.910](LP)[OM314.944] | 10.1969-12.1984 |
MERCEDES BENZ TRUCKS & BUSES | 911 5.7 | (LP)[OM352.907](LP)[OM352.986](LP)[OM353.909] | 01.1967-12.1969 |
MERCEDES BENZ TRUCKS & BUSES | Engine 3.8 | [314] | 04.1971-12.1988 |
MERCEDES BENZ TRUCKS & BUSES | O 302 5.7 | [OM352.980][OM352.993] | 12.1969-12.1974 |
MERCEDES BENZ TRUCKS & BUSES | O 302 8.7 | [OM360.916][OM360.979][OM360.980][OM360.981][OM360.985] | 05.1969-12.1974 |
MERCEDES BENZ TRUCKS & BUSES | O 305 8.7 | [OM360.911] | 01.1969-05.1973 |
MERCEDES BENZ TRUCKS & BUSES | O 309 D 3.8 | [OM314.946] | 01.1968-12.1969 |
MERCEDES BENZ TRUCKS & BUSES | O 309 D 3.8 | [OM314.948][OM314.959] | 09.1982- |
MERCEDES BENZ TRUCKS & BUSES | U 1000 5.7 | [OM353.962] | 01.1977-05.1988 |
MERCEDES BENZ TRUCKS & BUSES | U 1150 5.7 | [OM353.907] | 05.1988-02.2001 |
MERCEDES BENZ TRUCKS & BUSES | U 1150 5.7 | [OM353.940] | 05.1988-02.2001 |
Reference Information
6.05721E+11 5000080750 LRS00817 349581 21518501 5000808251 5001000127 296190700 455505 6.0572E+11 33419 11512401 DRS1420 EAA-111401 21518101 51.26201-7001 D3R24X6H7622 45-0091 551.207.093 22.0194 3151600180 8EA726023-001 1402081 0001402083 20401236EL 1402083 0001402081 A0011513701 986011550 CST10632ES 455615 1174631 10194P 51.26201-7099 0001402055 10194 0001402059 STR1232 11513701 220253 A0031515701 CS194 4139090014 5.1262E+11 860657GB A0031519501 LRS843 51.26201-9001 5710904 860660GB 5000241737 455926 5001014203 6010632 110512 90.80110-5190 8682 22626 A0031516001 1101616 0001415002 1416022 51.26201-7074 000986011550 256019 1416024 1414003 33583 MAV6480 21511301 5001014215 DRS1550 3367010 51.26201-78074 359581 51.26201-7112 0001416054 19082012 STRF014 51.26201-9099 239572 11513801 3285 220313 LR155-414B MAV126320 0001416047 1414010 A0011512401 LRS824 S0151 11514101 31516001 551.102.093 51.26201-7043 5000592182 5000789048 CGB-11524 A0021518101 220264 313360 22201 8123168 A0021518501 51.26201-7052 1416047 CST10632AS 45-1428 0001414010 31515701 STR22038 9.43217E+11 25841022 IM522 860653 51.26201-9074 31519501 S24BH0020A2 LRS00843 20401236BN 1402055 220219 8811550 1402059 MT43H A0021511301 0001416024 1415002 0001416022 254021M 254021L MAV1205 296190600 254021K 0001414003 4667 254021D 1416054 A0011514101 LRS817 1161473 7701007508 A003151600180 1516709R 72280 A0011513801 STRL310 19024024 S24BH0158A2 LRS00824 6104021Video/Publications
0001402055 0001402059 0001402081 0001402083 0001414003 0001414010 0001415002 0001416022 0001416024 0001416047 0001416054 0011514101 0021518501 0031515701 0031516001 03285 04667 0986011550 10194 10194P 110512 20401236BN 20401236EL 22.0194 22201 22626 254021D 254021K 254021L 254021M 256019 33419 33583 349581 359581 45-0091 45-1428 455505 455615 455926 5000080750 5000592182 5000789048 5001014203 5001014215 51.26201-7112 51.26201-9074 551.102.093 551.207.093 6010632 860653 860657GB 860660GB 8682 8811550 8EA726023-001 A0011514101 A0021518501 A0031515701 A0031516001 CGB-11524 CS194 CST10632AS CST10632ES DRS1420 DRS1550 EAA-111401 IM522 LRS00817 LRS00824 LRS00843 LRS817 LRS824 LRS843 MAV1205 MAV126320 MAV6480 STR22038 STRF014 STRL310 220219 220253 220264 220313 19082012 19024024Add Your Number
