Associated Numbers
0001123018 0001123019 02T911024 02T911024X 063521230180 0986020300 101393 101393B 114062 12100 220548 25-3369 300.570.102 3049 33198N 33198R 42020300 6010328 88212604 8EA012527-901 8EA738258-541 944280203000 AEY2198 BOS0001123018 CS1393 CST10328 CST10328AS CST10328ES CST10328GS CST10328OS CST10328RS DRT0300 DT1410 EAA-112235 EAA-121289 LRS02198 MRS20300 MSN2107 RAS41411 SG0667 STB1393 STR50237Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 233 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 52 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SEAT | Cordoba 1.4 TDi | [BNM] | 05.2005-11.2009 |
SEAT | Cordoba 1.9 SDi | [ASY] | 09.2002-11.2009 |
SEAT | Ibiza 1.4 TDi | [BNM] | 05.2005-11.2009 |
SEAT | Ibiza 1.9 SDi | [ASY] | 02.2002-12.2005 |
SKODA | Fabia 1.4 TDi | [BNM] | 02.2007-03.2010 |
SKODA | Fabia 1.4 TDi | [BNM] | 10.2005-03.2008 |
SKODA | Fabia 1.4 TDi | [BNM] | 10.2005-12.2007 |
SKODA | Fabia 1.4 TDi | [BNM] | 10.2007-03.2010 |
SKODA | Fabia 1.9 SDi | [ASY] | 04.2000-12.2007 |
SKODA | Fabia 1.9 SDi | [ASY] | 07.2001-12.2007 |
SKODA | Fabia 1.9 SDi | [ASY] | 11.1999-12.2007 |
SKODA | Fabia 1.9 SDi | [ASY] | 12.1999-03.2008 |
SKODA | Roomster 1.4 TDi | [BNM] | 03.2007-03.2010 |
SKODA | Roomster 1.4 TDi | [BNM] | 07.2006-03.2010 |
VW | Golf V 2.0 SDi | [BDK] | 01.2004-11.2008 |
VW | Golf V 2.0 SDi | [BDK] | 01.2004-11.2008 |
VW | Polo 1.4 TDi | [BNM] | 04.2005-11.2009 |
VW | Polo 1.4 TDi | [BWB] | 04.2005-11.2009 |
VW | Polo 1.9 SDi | [ASY] | 10.2001-11.2009 |
Reference Information
6010328 DRT0300 101393 101393B 300.570.102 STB1393 000986020300 CST10328OS MRS20300 25-3369 LRS02198 RAS41411 STR1691 220548 21911024 02T911024 CST10328AS 8EA738258-541 MSN2107 9.4428E+11 CST10328ES 114062 986020300 3049 42020300 SG0667 88212604 CST10328RS 02T911024X 8EA012527-901 33198R 1123019 1123018 CS1393 STR50237 DT1410 BOS0001123018 STRS511 LRS2198 63521230180 EAA-112235 AEY2198 CST10328 5010140 CST10328GS EAA-121289 S12BH0249A2 33198N MAV123280 12100 0001123019 0001123018Video/Publications
0001123018 0001123019 02T911024 02T911024X 063521230180 0986020300 101393 101393B 114062 12100 220548 25-3369 300.570.102 3049 33198N 33198R 42020300 6010328 88212604 8EA012527-901 8EA738258-541 944280203000 AEY2198 BOS0001123018 CS1393 CST10328 CST10328AS CST10328ES CST10328GS CST10328OS CST10328RS DRT0300 DT1410 EAA-112235 EAA-121289 LRS02198 LRS2198 MAV123280 MRS20300 MSN2107 RAS41411 SG0667 STB1393 STR50237 STRS511Add Your Number
