S0138 - Brand new AS-PL Starter motor

Brand new AS-PL Starter motor
Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 750.84 including GST

NZ$ 652.90 excluding GST
each
S0138
No stock in NZ
Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional
Purchase Qty:

0001241001 0001261001 0001261002 0001261025 0001261026 0001261027 0001261028 0986021480 101399 101399B 101399L 101399P 101399R 11.139.605 113891 115509 120-20160 1447911 1796026 19084003 19084018 19084253 19795N 2031368 2148650 2276131 260-24201 45-3443 72442833 80.137.01 8507 88213049 8EA012586-101 8EA738258-731 911.502.123 943213991010 AZF4876 BOS0001261028 CS1399 CST10682 CST10682AS CST10682ES CST10682GS CST10682OS CST10682RS DRT1480 DT2590 EAA-121175 F042002135 IS9457 LRS02272 MS758 MSRC1399 S0138 SG0100 STB1399 STB7399 STB9399 STM1399 STR50272 STR50465 UD10769S UD14986S UD30043S
Kilowatt5.5 kW
Length (L.1)319 mm
Mount Hole Center - Center (O.1)127 mm
Mount Hole Center - Center (O.2)127 mm
Mount Hole Center - Center (O.3)127 mm
Mount Hole Diameter (C.1)13.5 mm
Mount Hole Diameter (C.2)13.5 mm
Mount Hole Diameter (C.3)13.5 mm
No./Mount holes3 qty
No./Mount holes with thread0 qty
No./Teeth12 qty
No./Teeth (Replaces)12 qty
Pinion at Rest (B)48 mm
RotationCW
Spigot Diameter (A)92 mm
Unit TypeBOSCH
Voltage24 V
Make Model Type Year
SCANIA 230 11.7 [DC12.13] 09.2005-
SCANIA 230 8.9 [DC9.13] 01.2008-
SCANIA 230 8.9 [DC9.13] 08.2006-
SCANIA 230 8.9 [DC9.13] 09.2004-
SCANIA 230 8.9 [DC9.13] 09.2007-
SCANIA 230 8.9 [DC9.16] 01.2008-
SCANIA 230 8.9 [DC9.16] 04.2006-
SCANIA 230 8.9 [DC9.16] 08.2006-
SCANIA 230 8.9 [DC9.16] 09.2004-
SCANIA 230 8.9 [DC9.16] 09.2005-
SCANIA 230 8.9 [DC9.16] 09.2007-
SCANIA 230 8.9 [DC9.18] 09.2004-
SCANIA 230 9.3 [DC9.30] 09.2007-
SCANIA 230 9.3 [DC9.35] 09.2007-
SCANIA 230 9.3 [DC9.39] 09.2007-
SCANIA 250 9.3 [DC09.111] 09.2013-
SCANIA 270 11.7 [DC12.17] 04.2004-
SCANIA 270 8.9 [DC9.12] 04.2004-
SCANIA 270 8.9 [DC9.12] 08.2006-
SCANIA 270 8.9 [DC9.12] 09.2004-
SCANIA 270 8.9 [DC9.17] 04.2004-
SCANIA 270 8.9 [DC9.17] 08.2006-
SCANIA 270 8.9 [DC9.17] 09.2004-
SCANIA 280 9.3 [DC09.113] 07.2009-
SCANIA 280 9.3 [DC09.113] 08.2012-
SCANIA 280 9.3 [DC09.113] 09.2009-
SCANIA 280 9.3 [DC09.113] 09.2013-
SCANIA 280 9.3 [DC9.29] 07.2009-
SCANIA 280 9.3 [DC9.29] 09.2007-
SCANIA 280 9.3 [DC9.29] 09.2009-
SCANIA 280 9.3 [DC9.36] 07.2009-
SCANIA 280 9.3 [DC9.36] 08.2012-
SCANIA 280 9.3 [DC9.36] 09.2009-
SCANIA 280 9.3 [DC9.36] 09.2013-
SCANIA 280 9.3 [DC9.38] 07.2009-
SCANIA 280 9.3 [DC9.38] 08.2012-
SCANIA 280 9.3 [DC9.38] 09.2009-
SCANIA 280 9.3 [DC9.38] 09.2013-
SCANIA 310 8.9 [DC9.11] 01.2008-
SCANIA 310 8.9 [DC9.11] 04.2004-
SCANIA 310 8.9 [DC9.11] 08.2006-
SCANIA 310 8.9 [DC9.11] 09.2004-
SCANIA 310 8.9 [DC9.17] 04.2004-
SCANIA 310 8.9 [DC9.18] 04.2004-
SCANIA 310 8.9 [DC9.18] 08.2006-
SCANIA 310 8.9 [DC9.18] 09.2004-
SCANIA 320 9.3 [DC09.108] 07.2009-
SCANIA 320 9.3 [DC9.22] 07.2009-
SCANIA 320 9.3 [DC9.22] 09.2009-
SCANIA 320 9.3 [DC9.32] 07.2009-
SCANIA 320 9.3 [DC9.32] 09.2009-
SCANIA 320 9.3 [DC9.37] 07.2009-
SCANIA 320 9.3 [DC9.37] 09.2009-
SCANIA 340 10.6 [DC11.08] 03.2004-
SCANIA 340 10.6 [DC11.08] 04.2004-
SCANIA 340 10.6 [DC11.08] 09.2004-
SCANIA 340 11.7 [DC12.10] 04.2004-
SCANIA 340 11.7 [DC12.10] 08.2004-
SCANIA 340 11.7 [DC12.10] 08.2006-
SCANIA 340 11.7 [DC12.10] 10.2006-
SCANIA 340 11.7 [DC12.13] 09.2005-
SCANIA 340 11.7 [DC12.17] 09.2005-
SCANIA 340 11.7 [DC12.26] 08.2004-
SCANIA 360 12.7 [DC13.06] 04.2010-
SCANIA 360 12.7 [DC13.06] 08.2010-
SCANIA 360 12.7 [DC13.06] 09.2009-
SCANIA 360 12.7 [DC13.114] 04.2010-
SCANIA 360 9.3 [DC09.112] 09.2013-
SCANIA 380 10.6 [DC11.09] 03.2004-
SCANIA 380 10.6 [DC11.09] 04.2004-
SCANIA 380 10.6 [DC11.09] 09.2004-
SCANIA 380 11.7 [DC12.13] 03.2008-
SCANIA 380 11.7 [DC12.13] 04.2004-
SCANIA 380 11.7 [DC12.13] 04.2010-
SCANIA 380 11.7 [DC12.13] 08.2004-
SCANIA 380 11.7 [DC12.13] 09.2004-
SCANIA 380 11.7 [DC12.13] 09.2005-
SCANIA 380 11.7 [DC12.13] 10.2006-
SCANIA 380 11.7 [DC12.17] 03.2008-
SCANIA 380 11.7 [DC12.17] 09.2005-
SCANIA 380 11.7 [DC12.18] 04.2004-
SCANIA 400 12.7 [DC13.05] 01.2010-
SCANIA 400 12.7 [DC13.05] 03.2008-
SCANIA 400 12.7 [DC13.05] 04.2010-
SCANIA 400 12.7 [DC13.05] 07.2009-
SCANIA 400 12.7 [DC13.05] 08.2010-
SCANIA 400 12.7 [DC13.103] 08.2010-
SCANIA 400 12.7 [DC13.113] 01.2010-
SCANIA 400 12.7 [DC13.113] 03.2009-
SCANIA 420 11.7 [DC12.06] 03.2004-
SCANIA 420 11.7 [DC12.06] 09.2005-
SCANIA 420 11.7 [DC12.06] 09.2007-
SCANIA 420 11.7 [DC12.14] 01.2008-
SCANIA 420 11.7 [DC12.14] 03.2004-
SCANIA 420 11.7 [DC12.14] 04.2004-
SCANIA 420 11.7 [DC12.14] 08.2006-
SCANIA 420 11.7 [DC12.14] 09.2004-
SCANIA 420 11.7 [DC12.15] 02.2006-
SCANIA 420 11.7 [DC12.15] 03.2004-
SCANIA 420 11.7 [DC12.15] 04.2004-
SCANIA 420 11.7 [DC12.15] 08.2006-
SCANIA 420 11.7 [DC12.15] 09.2004-
SCANIA 420 11.7 [DT12.11] 03.2004-
SCANIA 420 11.7 [DT12.12] 01.2008-
SCANIA 420 11.7 [DT12.12] 03.2004-
SCANIA 420 11.7 [DT12.12] 09.2004-
SCANIA 420 11.7 [DT12.12] 09.2005-
SCANIA 420 11.7 [DT12.14] 09.2005-
SCANIA 440 12.7 [DC13.10] 01.2010-
SCANIA 440 12.7 [DC13.10] 03.2008-
SCANIA 440 12.7 [DC13.10] 04.2010-
SCANIA 440 12.7 [DC13.10] 07.2009-
SCANIA 440 12.7 [DC13.10] 08.2010-
SCANIA 440 12.7 [DC13.109] 01.2010-
SCANIA 440 12.7 [DC13.109] 04.2010-
SCANIA 440 12.7 [DC13.112] 01.2010-
SCANIA 440 12.7 [DC13.112] 07.2009-
SCANIA 440 12.7 [DC13.121] 01.2010-
SCANIA 450 12.7 [DC13.124] 09.2013-
SCANIA 470 11.7 [DT12.03] 03.2004-
SCANIA 470 11.7 [DT12.03] 04.2004-
SCANIA 470 11.7 [DT12.06] 03.2004-
SCANIA 470 11.7 [DT12.06] 09.2005-
SCANIA 480 11.7 [DT12.03] 04.2004-
SCANIA 480 11.7 [DT12.17] 01.2008-
SCANIA 480 11.7 [DT12.17] 03.2008-
SCANIA 480 11.7 [DT12.17] 04.2004-
SCANIA 480 11.7 [DT12.17] 08.2006-
SCANIA 480 12.7 [DC13.07] 01.2010-
SCANIA 480 12.7 [DC13.07] 03.2008-
SCANIA 480 12.7 [DC13.07] 04.2010-
SCANIA 480 12.7 [DC13.07] 08.2010-
SCANIA 480 12.7 [DC13.110] 04.2010-
SCANIA 480 12.7 [DC13.110] 08.2010-
SCANIA 480 12.7 [DC13.110]
SCANIA 480 12.7 [DC13.111] 01.2010-
SCANIA 480 12.7 [DC13.111] 04.2010-
SCANIA 480 12.7 [DC13.111] 08.2010-
SCANIA 480 12.7 [DC13.111]
SCANIA 490 12.7 [DC13.125] 09.2013-
SCANIA G 230 9.3 [DC9.30] 09.2007-
SCANIA G 230 9.3 [DC9.35] 09.2007-
SCANIA G 230 9.3 [DC9.39] 09.2007-
SCANIA G 420 11.7 [DC12.06] 01.2008-
SCANIA G 440 11.7 [DT12.18] 01.2008-
SCANIA G 440 11.7 [DT12.18] 10.2007-
SCANIA G 440 12.7 01.2012-
SCANIA G 460 12.7 05.2013-
SCANIA G 460 12.7 09.2013-
SCANIA G 470 11.7 [DT12.06] 01.2010-
SCANIA G 480 12.7 [DC13.07] 01.2012-
SCANIA G 480 12.7 [DC13.111] 01.2012-
SCANIA P 230 9.3 [DC9.30] 09.2007-
SCANIA P 230 9.3 [DC9.35] 09.2007-
SCANIA P 230 9.3 [DC9.39] 09.2007-
SCANIA P 270 8.9 01.2012-
SCANIA P 270 9.3 [DC09.E02] 01.2012-
SCANIA P 310 8.9 07.2007-06.2012
SCANIA P 310 9.0 [DC9.11] 01.2010-
SCANIA P 310 9.3 [OC9.G05] 01.2011-
SCANIA P 340 11.0 [DC11.08] 01.2008-
SCANIA P 340 11.0 [DC11.08] 04.2004-
SCANIA P 340 11.0 [DC11.08] 09.2004-
SCANIA P 340 9.3 [OC09.102] 01.2011-
SCANIA P 360 12.7 01.2012-
SCANIA P 380 11.0 [DC11.09] 04.2004-
SCANIA P 400 12.7 [DC13.05] 09.2007-
SCANIA P 400 12.7 [DC13.113] 09.2007-
SCANIA P 420 11.7 [DC12.06] 01.2005-12.2011
SCANIA P 420 11.7 [DC12.06] 01.2008-
SCANIA P 420 11.7 [DC12.14] 01.2005-12.2011
SCANIA P 420 11.7 [DC12.15] 01.2005-12.2011
SCANIA P 420 11.7 [DC12.22] 01.2005-12.2011
SCANIA P 420 11.7 [DT12.11] 01.2005-12.2011
SCANIA P 420 11.7 [DT12.12] 01.2005-12.2011
SCANIA R 440 11.7 [DT12.18] 01.2008-
SCANIA R 440 12.7 [DC13.10] 01.2012-
SCANIA R 440 12.7 [DC13.10] 10.2012-
SCANIA R 440 12.7 [DC13.109] 01.2012-
SCANIA R 440 12.7 [DC13.112] 01.2012-
SCANIA R 450 12.7 [DC13.147] 09.2013-
SCANIA R 470 11.7 [DT12.03] 03.2004-
SCANIA R 470 11.7 [DT12.06] 03.2004-
SCANIA R 480 12.7 [DC13.07] 01.2012-
SCANIA R 480 12.7 [DC13.110] 01.2012-
SCANIA R 480 12.7 [DC13.111] 01.2012-
UD10769S EAA-121175 573507 220993 M9T65971 6010682.1 8013701 8EA738258-731 STR50533 IS9457 WOOSTR50533 UD30043S CST10682GS 000986021480 20401286OE STR1345 1261025 DRT1480X LRS02272 1261028 1261027 911.502.123.280 DRT1480 1261026 PRSS335 ANM23700X 101399 11.139.605 113891 260-24201 DRT1480N 911.502.123.210 911.502.123.211 1241001 911.502.123.215 571467 72442833 S0138 ZM8013701 BOS0001261028 2031368 0001986S10002 CGB-22148 0001261025 1261002 911.502.123.500 1261001 STM670 81261001 0001261028 1986S10002 0001261026 120-20160 0001261027 MAV126820 M90R3545SE 911.502.123.900 STR50465 M009T65971 STB9399 WOOSTR50465 F042002153 MSRC1399 STRS335 2029376 19795N STM1399 STR79692 M009T65971ZA 0001261002 115509 19084018 CGB-53443 0001261001 STR1420 579261 19802N 1261106 20401286BN 1261105 45-3443 M009T65971AM UD14986S 1447911 SG0100 2276131 000F042002135 19084253 911.502.123.011 101399B STB7399 8EA012586-101 S24BH0123 911.502.123.018 579271 0001241001 101399P F042002135 S24BH0123A2 101399L 911.502.123.010 CS1399 9.43214E+11 101399R MS758 LRS2272 88213049 STR50272 986021480 1180999 19084003 0001986S10047 8507 2148650 WOOSTR50272 6.7020.1 CST10682AS DT2590 AZF4876 M9T65971AM 0001261105 0001261106 1986S10047 000F042002153 6010682 STB1399 1796026 2708317
STM670 6010682.1 6010682.0 20401286BN 20401286OE 6.7020.1 911.502.123.211 911.502.123.280 911.502.123.011 911.502.123.010 911.502.123.215 0001261105 0001241001 0001261001 0001261002 0001261025 0001261026 0001261027 0001261028 0986021480 101399 101399B 101399L 101399P 101399R 11.139.605 113891 115509 120-20160 1447911 1796026 19084003 19084018 19084253 19795N 1986S10002 2031368 2148650 2276131 260-24201 2708317 45-3443 72442833 80.137.01 8507 88213049 8EA012586-101 8EA738258-731 943213991010 AZF4876 BOS0001261028 CGB-22148 CS1399 CST10682 CST10682AS CST10682ES CST10682GS CST10682OS CST10682RS DRT1480 DT2590 EAA-121175 F042002135 IS9457 LRS02272 LRS2272 MAV126820 MS758 MSRC1399 S0138 SG0100 STB1399 STB7399 STB9399 STM1399 STR50272 STR50465 STRS335 UD10769S UD14986S UD30043S 220993
