Associated Numbers
0001360063 0001368020 0986011330 0986011331 10394M 11.130.124 11.130.490 110518 11430 18033N 20401437BN 20404206OE 20500847 22.0394 28.0394M 33353 42498145 42498212 45-0228 455518 4706008 4716026 4716062 4737756 4755111 4807379 501.002.093 6010734 6030602 63216703 63216740 63216741 77050262 77050562 77711817 858320 860817 8665 8811330 8EA726142-001 AES8141 AZJ3131 AZJ3515 CS394 CST10734AS CST30602GS CST30602OS DRS1330 EAA-111051 GS216741M-R GS368020-A IS0490 LRS00841 MT67C MT67CA MT67CB S0092 STR22010 UD03445S
0001360063 Bosch
0001368020 Bosch show
004755111 Unic Simca
04755111
04807379
063216740 Magneti Marelli
063216741 Magneti Marelli
0986011330 Bosch ruil
0986011331 Bosch ruil
11011060 EuroTec
11011330 EuroTec
110518 Cargo
11130124 Mahle show
11130490 Mahle show
111989 Cargo
113277 Cargo
120571 PIC
1368020 Iveco
15000 Efel
1548SP Spidan
18033 Lester
18093 Lester
182118 PIC
19024256 Remy
30281020 Magneti Marelli
33353 EAI
36127 Sparex
42498145 Fiat
42498212 Fiat
42498505 Fiat
450228 Valeo
455518 Valeo
4706008 Fiat
4716026 Fiat
4716062 Fiat
4737756 Fiat
4755111 Fiat
4807379 Fiat
501002093 PSH
63216703 Magneti Marelli
63216740 Magneti Marelli
63216741 Magneti Marelli
63216741010 Magneti Marelli
720046 Kager
72735814 Mahle
77050262 Fiat
77050562 Fiat
858320 Prestolite
859542 Prestolite
8665 CEVAM
8811330 Friesen
8811330F Friesen
8EA726142001 Hella
91157153 Wilson
91192509 Wilson
943252228 Magneti Marelli
A11330 ATL
A13420 ATL
A71930 ATL
ALT2057 Unipoint
ALTH250 Unipoint
AZJ3131 Mahle show
AZJ3515 Mahle
CS394 HC
CS490 HC
DEM203 ADI
DEM220 ADI
DRS1330 Remy
F042S02089 Bosch
HCS394 HC
IS0124 Mahle
IS0490 Mahle
IS9446 Mahle
LRS00841 Lucas
LRS841 Lucas
MS186 Mahle show
MSN521 Magneti Marelli
MT67C Magneti Marelli
MT67CA Magneti Marelli
MT67CB Magneti Marelli
SM2510 Honda
STR2316 Unipoint
STR368020 Stabeco
ZB2998201 CAV
J&N 410-24057
Bosch 0001368020
References:
Bosch 0001368020
Lester 18033
MAHLE IS0490, MS186
Bosch 0001231011
Magneti Marelli MSN2045
MAHLE MS248
References:
J&N 410-24233
Bosch 0001231011, F042002089
Lester 18959
Magneti Marelli 063522310110, MSN2045
MAHLE 11131452, IS1169, MS248
PIC Picture ID 120-6062
Magneti Marelli 063522310110
Substitutes:
J&N 410-24057
Bosch 0001231011
MAHLE MS248
References:
J&N 410-24057
Bosch 0001231011, 0001368020
Magneti Marelli 063522310110
MAHLE MS248
MAHLE 11131452, AZF4121, IS1169
Substitutes:
J&N 410-24057
Magneti Marelli MSN2045
References:
J&N 410-24057
Bosch 0001231011, 0986019010
Lucas LRS1942
Magneti Marelli MSN2045
MAHLE IS1169
Specifications
| Kilowatt | 4 kW |
| Length (L.1) | 341 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Center - Center (O.2) | 104 mm |
| Mount Hole Center - Center (O.3) | 146 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| Mount Hole Diameter (C.3) | 12 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | 100 E 15 6.0 | [8060.25.4200LTC][8060.45.5000][8060.45.5001][8060.45.5003][8060.45.5005] | 01.1991- |
| IVECO | 100 E 18 6.0 | [8060.25V.4000TC] | 01.1991- |
| IVECO | 100 E 21 6.0 | [8060.25.4280LTC][8060.254200] | 12.1991- |
| IVECO | 100 E 21 6.0 | [8060.45.4180TCA] | 01.1991- |
| IVECO | 120 E 18 6.0 | [8060.25V.4080TC] | 01.1992-07.2000 |
| IVECO | 120 E 23 6.0 | [8060.45.6090] | 01.1992-08.2000 |
| IVECO | 120 E 23 6.0 | [8060.45S.6800TCA] | 01.1992-08.2000 |
| IVECO | 130 E 15 6.0 | [8060.25.4280LTC] | 01.1994-07.2000 |
| IVECO | 130 E 18 6.0 | [8060.25V.4080TC] | 01.1992-07.2000 |
| IVECO | 130 E 23 6.0 | [8060.45.6090][8060.45S.6000TCA] | 01.1992- |
| IVECO | 135 E 18 6.0 | [8060.25VTC] | 01.1993-07.2000 |
| IVECO | 135 E 23 6.0 | [8060.45STCA] | 01.1993- |
| IVECO | 150 E 15 6.0 | [8060.25.4280LTC] | 01.1992-12.1996 |
| IVECO | 150 E 18 6.0 | [8060.25V.4000TC][8060.25V.4080TC] | 01.1992-07.2000 |
| IVECO | 150 E 23 6.0 | [8060.45.6090][8060.45S.6800TCA] | 01.1992-07.2000 |
| IVECO | 170 E 18 5.8 | [8060.25VTC] | 01.1994-07.2000 |
| IVECO | 170 E 23 5.8 | [8060.45STCA] | 01.1994- |
| IVECO | 180 E 21 6.0 | [8060.45.4100TCA] | 04.1992-07.2000 |
| IVECO | 260 E 23 6.0 | [8060.45S.6000TCA] | 01.1992-07.2000 |
| IVECO | 280 E 23 6.0 | [8060.45S.6000TCA] | 01.1992-11.2000 |
| IVECO | 50-10 4.6 | [8340.04.200][8340.04.250][8340.04.300][8340.04.362] | 01.1979-10.1983 |
| IVECO | 60-10 4.6 | [8340.04.200][8340.04.250] | 05.1982-12.1986 |
| IVECO | 65-10 4.6 | [8340.04.200][8340.04.250][8340.04.300][8340.04.350] | 05.1982-01.1987 |
| IVECO | 70-12 5.4 | [8340.05.200] | 01.1983-01.1985 |
| IVECO | 70-14 5.7 | [8060.05.246][8060.05.285] | 05.1988-06.1991 |
| IVECO | 75 E 15 6.0 | [8060.25.4200LTC] | 01.1991-09.2000 |
| IVECO | 79-10 4.6 | [8340.04.200][8340.04.300] | 01.1983-01.1987 |
| IVECO | 79-14 5.9 | [8060.05.280] | 07.1988-03.1991 |
| IVECO | 80 E 15 6.0 | [8060.25.4200LTC] | 01.1991-08.2000 |
| IVECO | 80 E 18 6.0 | [8060.25V.4000TC] | 01.1991-08.2000 |
| IVECO | 80 E 21 6.0 | [8060.45.4100TCA][8060.45.4180TCA] | 01.1991-08.2000 |
| IVECO | 8360 8.1 | [8360.05.200] | 06.1983-12.1990 |
| IVECO | 8361 8.0 | [8361.25.540..] | 01.1992-12.2002 |
| IVECO | 95 E 15 6.0 | [8060.25.4755] | 11.1993-12.1994 |
| IVECO | 95 E 15 6.0 | [8060.25.4755][8060.25.4760][8060.25.4764] | 11.1993-12.1994 |
| IVECO | 95 E 15 6.0 | [8060.45.4702] | 11.1993-12.1994 |
| IVECO | 95 E 15 6.0 | [8060.45.5050] | 11.1993-08.2000 |
| IVECO | 95 E 15 6.0 | [8060.45.5051] | 11.1993-08.2002 |
| IVECO | 95 E 21 6.0 | [8060.45.4700][8060.45.4704][8060.45.4706] | 11.1993-12.2000 |
| IVECO | 95 E 21 6.0 | [8060.45.4708] | 11.1993-12.2000 |
| IVECO | 95 E 21 6.0 | [8060.45.5250][8060.45.5251][8060.45.5255] | 11.1993-08.2000 |
| IVECO | M 115-17 5.5 | [8060.24.601] | 09.1983-12.1985 |
| IVECO | M 115-17 5.7 | [8060.25.600] | 01.1986-12.1999 |
| IVECO | M 115-17 5.9 | [8060.25.600] | 01.1986-12.1999 |
| IVECO | M 135-17 5.5 | [8060.24.601] | 09.1983-12.1985 |
| IVECO | M 135-17 5.9 | [8060.25.600] | 01.1986-08.1992 |
| IVECO | M 145-17 5.9 | [8060.25.600] | 02.1986-07.1992 |
| IVECO | M 159-17 8.1 | [8360.05.254] | 07.1982-09.1986 |
| IVECO | M 175-17 5.9 | [8060.25.600] | 09.1986-07.1992 |
| IVECO | P/PA 159-17 8.1 | [8360.05.254] | 07.1982-09.1986 |
| URSUS | 912 | 09.1988-12.1990 |
Alternatives >>>
S0080 - Gear reduction type
Reference Information
501.002.093 CST10734AS AZJ3515 8811330 4706008 42498145 28.0394M 4737756 MT67CA S24BH0036A2 GS216741M-R 0001360063 6010734 6030602 611466632 1368020 CST30602GS 22.0394 0001368020 5110012 MS 8665 77050562 220267 331920 20401437BN UD03445S 18033N 11.130.490 42498212 000986011330 860817 11.130.124 11430 1360063 DRS1330 AES8141 63216703 77711817 20404206OE LRS00841 000986011331 GS368020-A 63216740 MAV2060 S0092 10394M CS394 STR22010 45-0228 611466612 LRS841 33353 CST30602OS CGB-21330 AZJ3131 STR79016 STR10079 858320 77050262 MAV2050 4716026 110518 ANM13550X 4755111 4716062 8EA726142-001 186 EAA-111051 STRL034 986011330 455518 986011331 4807379 1516760R IS0490 MT67CVideo/Publications
0001360063 0001368020 0986011330 0986011331 10394M 11.130.124 11.130.490 110518 11430 18033N 20401437BN 20404206OE 22.0394 28.0394M 33353 42498145 42498212 45-0228 455518 4706008 4716026 4716062 4737756 4755111 4807379 501.002.093 6010734 6030602 63216703 63216740 77050262 77050562 77711817 858320 860817 8665 8811330 8EA726142-001 AES8141 AZJ3131 AZJ3515 CGB-21330 CS394 CST10734AS CST30602GS CST30602OS DRS1330 EAA-111051 GS216741M-R GS368020-A IS0490 LRS00841 LRS841 MAV2050 MAV2060 MS 186 MT67C MT67CA S0092 STR22010 STRL034 UD03445S 220267Add Your Number
