Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 281.06 including GST
NZ$ 244.40 excluding GST
or four payments of $70.27
with
Learn More
UOM:
each
Product Code:
S0056
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
0001108092 0986016560 10878 112305 11799 17276N 20401792BN 22.0878 25-1282 26-1282 3683 458517 6010297 8016560 8212662 8826851 8EA732657-001 AES9194 CS878 CST10297AS DRS6560 EAA-121636 LRS00994 STR50131Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 243 mm |
| Mount Hole Center - Center (O.1) | 111.50 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 18.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SAAB | 9000 2.3 -16 | [B234I] | 08.1989-08.1993 |
| SAAB | 9000 2.3 -16 Aero CS | [B234] | 02.1993-08.1993 |
| SAAB | 9000 2.3 -16 CS | [B234I] | 09.1989-08.1993 |
| SAAB | 9000 2.3 -16 Turbo | [B234L] | 09.1990-08.1993 |
| SAAB | 9000 2.3 -16 Turbo CS | [B234L] | 09.1990-08.1993 |
| SAAB | 900 2.1 -16 | [B212I] | 08.1990-08.1993 |
Reference Information
| 0001108092 | BOSCH |
| 0986016560 | BOSCH |
| 10878 | KUHNER |
| 112305 | CARGO |
| 11799 | EAI |
| 17276N | WAI / TRANSPO |
| 20401792BN | REAL |
| 220187 | ERA |
| 22.0878 | LAUBER |
| 25-1282 | ELSTOCK |
| 26-1282 | ELSTOCK |
| 3683 | CEVAM |
| 458517 | VALEO |
| 470.502.092.010 | PSH |
| 470.502.092.018 | PSH |
| 470.502.092.395 | PSH |
| 470.502.092.461 | PSH |
| 470.502.092.608 | PSH |
| 6010297.0 | SANDO |
| 8016560 | FRIESEN |
| 8212662 | POWERMAX |
| 8826851 | SAAB |
| 8977498 | SAAB |
| 8EA732657-001 | HELLA |
| AES9194 | AUTOELECTRO |
| AM-2092 | AUTO MAGNETO |
| ANM18780X | ANDEL |
| CS878 | HC PARTS |
| CST10297AS | CASCO |
| DRS6560 | DELCO |
| F032112305 | CARGO |
| LRS00994 | LUCAS |
| LRS994 | LUCAS |
| MAV122970 | SIOM |
| PRSF229 | 3EFFE |
| S132.646 | PSH |
| S148.592 | PSH |
| STR1309 | ELECTROLOG |
| STR50131 | WOODAUTO |
| STRF229 | 3EFFE |
| STX200886 | STARDAX |
Video/Publications
