Associated Numbers
0001110016 0001110075 0001110091 0001110112 0031515001 0041514501 0041516501 0041517001 0986013150 10360 111851 11284 17038N 17698N 20401821BN 20500656 22.0360 25-1252 3565 42013150 438199 455674 6010128 8013150 8212905 88212905 8EA726108-001 A0031515001 A0041514501 A0041516501 A0041517001 AES6156 AEY2028 CS360 CST10128AS DRS3150 DRS3150N EAA-121275 IS9430 LRS00656 LRS02028 S1057B S1058B SS850 STR50023 VS308Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 270 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Korando 3.2 | [M104.995] | 01.1999- |
DAEWOO | Korando 3.2 | [M104.995] | 01.1999- |
MAYBACH | Maybach 5.5 V12 | [M285.950] | 09.2002- |
MERCEDES BENZ | 190 E 2.6 | (201)[M103.942] | 09.1986-08.1993 |
MERCEDES BENZ | 260 E 2.6 | (124)[M103.940] | 09.1985-08.1992 |
MERCEDES BENZ | 260 E 2.6 4-Matic | (124)[M103.940] | 12.1986-12.1989 |
MERCEDES BENZ | 260 E 2.6 4-Matic | (124)[M103.943] | 09.1986-08.1992 |
MERCEDES BENZ | 260 SE 2.5 | (126)[M103.941] | 09.1985-06.1991 |
MERCEDES BENZ | 280 E 2.8 | (124)[M104.942] | 10.1992-06.1993 |
MERCEDES BENZ | 280 TE 2.8 | (124)[M104.942] | 10.1992-06.1993 |
MERCEDES BENZ | 300 CE-24 3.0 | (124)[M104.980] | 09.1989-12.1992 |
MERCEDES BENZ | 300 E-24 3.0 | (124)[M104.980] | 09.1988-08.1992 |
MERCEDES BENZ | 300 E 2.9 | (124)[M103.980] | 06.1985-12.1985 |
MERCEDES BENZ | 300 E 3.0 | (124)[M103.983] | 08.1985-08.1992 |
MERCEDES BENZ | 300 E 3.0 4-Matic | (124)[M103.983] | 09.1986-02.1992 |
MERCEDES BENZ | 300 E 3.0 4-Matic | (124)[M103.985] | 09.1986-06.1993 |
MERCEDES BENZ | 300 SE 2.9 | (126)[M103.981] | 01.1986-06.1991 |
MERCEDES BENZ | 300 SE 3.2 | (140)[M104.990] | 03.1991-05.1993 |
MERCEDES BENZ | 300 SE 3.2 | (140)[M104.994] | 03.1991-04.1993 |
MERCEDES BENZ | 300 SEL 2.9 | (126)[M103.981] | 09.1986-06.1991 |
MERCEDES BENZ | 300 SEL 3.2 | (140)[M104.990] | 03.1991-05.1993 |
MERCEDES BENZ | 300 SEL 3.2 | (140)[M104.994] | 05.1993-10.1998 |
MERCEDES BENZ | 300 SL-24 3.0 | (129)[M104.981] | 03.1989-07.1993 |
MERCEDES BENZ | 300 SL 2.9 | (107)[M103.982] | 09.1985-08.1989 |
MERCEDES BENZ | 300 SL 3.0 | (129)[M103.984] | 03.1989-08.1993 |
MERCEDES BENZ | 320 CE 3.2 | (124)[M104.992] | 10.1992-05.1993 |
MERCEDES BENZ | 320 E 3.2 | (124)[M104.992] | 10.1992-06.1993 |
MERCEDES BENZ | 600 SE 6.0 | (140)[M120.980] | 04.1991-09.1998 |
MERCEDES BENZ | C 280 2.8 | (202)[M104.941] | 05.1993-05.1997 |
MERCEDES BENZ | C 36 AMG 3.6 | (202)[M104.941] | 01.1994-05.1997 |
MERCEDES BENZ | E 280 2.8 | (124)[M104.942] | 06.1993-06.1996 |
MERCEDES BENZ | E 280 3.0 | (124)[M104.942] | 06.1993-06.1995 |
MERCEDES BENZ | E 280 E 2.8 | (210)[M104.945] | 01.1996-02.1997 |
MERCEDES BENZ | E 300 3.0 4-Matic | (124)[M103.985] | 06.1993-06.1995 |
MERCEDES BENZ | E 300 CE 3.0 | (124)[M103.983] | 03.1987-05.1993 |
MERCEDES BENZ | E 300 CE 3.0 | (124)[M103.983] | 03.1987-12.1989 |
MERCEDES BENZ | E 320 3.2 | (124)[M104.992] | 06.1993-06.1998 |
MERCEDES BENZ | E 320 3.2 | (124)[M104.995] | 06.1993-06.1998 |
MERCEDES BENZ | E 320 3.2 | (210)[M104.992] | 06.1995-02.1997 |
MERCEDES BENZ | E 36 AMG 3.6 | (124)[M104.992] | 03.1993-02.1994 |
MERCEDES BENZ | G 320 3.2 | (463)[M104.996] | 09.1994-11.1997 |
MERCEDES BENZ | S 280 2.8 | (140)[M104.944] | 02.1993-10.1998 |
MERCEDES BENZ | SL 280 2.3 | (129)[M104.943] | 08.1993-05.1998 |
MERCEDES BENZ | SL 320 3.2 | (129)[M104.991] | 09.1993-05.1998 |
SSANGYONG | Korando 3.2 | [M104.995] | 01.1999- |
SSANGYONG | Korando 3.2 4WD | [M104.995] | 07.1996-12.2000 |
SSANGYONG | Musso 3.2 4WD | [M104.992] | 06.1996- |
Reference Information
1110112 AEY2028 0001110112 AES6156 51516601 41518901 71518901 1110075 STR1172 STRW218 1611513001 1621513001 LRS00656 R5134510AB A005151130180 8013150 5010448 1621513401 A0041514501 5103581AB 550.501.102.010 4151890180 25-1252 LRS02028 51511301 123 0001110091 5103581AA STR00301 000986013150 A004151970180 41519201 A0061513001 A0041517001 111851 11284 41513901 220134 EAA-121275 A0061513401 A0041519701 20500656 41516501 A004151700180 550.501.102.215 3151500180 05103581AA 05103581AB 4151700180 S1058B 10360 A004151920180 CS360 A0051516601 A004151450180 986013150 8EA726108-001 0001110075 550.501.102.500 550.501.102.900 550.501.102.901 438199 6010128 VS308 31515001 71519201 455674 17698N 05134510AA A004151650180 A0031515001 5151660180 A0041519201 A003151500180 S1057B DRS3150N 5151660183 CST10128AS A0071519201 05134510AB 41514501 003-130116 5151130180 05073919AA 3130116 42013150 MAV3120 4151450180 4151920180 MS MT130116 330512 PRSW218 A0041518901 ANM15370X 550.501.102 MS123 5073919AA CS1044 S0029 1005831549 3565 5134510AA 5134510AB DRS3150 1110016 STM762 17038N A1005831549 SS850 4151650180 0001110016 22.036 A005151660183 550.501.102.018 A005151660180 IS9430 1110091 LRS2028 A0071518901 4151970180 A004151890180 A0041516501 550.501.102.550 S12BH0468A2 88212905 LRS656 20401821BN 41519701 A0041513901 61513401 A1611513001 1516655R 41517001 61513001 8212905 STR10283Video/Publications
0001110016 0001110075 0001110091 0001110112 003-130116 0031515001 0041514501 0041516501 0041517001 0986013150 10360 111851 11284 17038N 17698N 20401821BN 20500656 22.0360 25-1252 3130116 3565 42013150 438199 455674 550.501.102 550.501.102.900 550.501.102.901 6010128 8013150 8212905 88212905 8EA726108-001 A0031515001 A0041514501 A0041516501 A0041517001 AES6156 AEY2028 CS1044 CS360 CST10128AS DRS3150 DRS3150N EAA-121275 IS9430 LRS00656 LRS02028 LRS2028 LRS656 MAV3120 MS 123 MT130116 S0029 S1057B S1058B SS850 STR50023 STRW218 VS308 220134Add Your Number
