Associated Numbers
0001110132 063280077010 063521101320 063721135010 0986018680 112006 11941 190.533.092 201135 20401311 20432203 20510182 220094 25-2477 28100-0B010 28100-0B020 28100-0G010 28100-0G020 28100-0G021 31183N 458514 6.0051.9 6010113 6040302 88212897 8EA011610-631 8EA737543-001 943211351010 944280186800 9521 BOS0001110132 CST10113 CST10113AS CST10113ES CST10113GS CST10113OS CST10113RS CST40302 CST40302AS CST40302ES CST40302GS CST40302OS CST40302RS DENDSN950 DRS8680 DS9790 DSN950 EAA-121019 J5212117 JS1135 LRS02099 MRS18680 MSN2148 MSN8077 MSRC1135 RAS39791 S0020 S1049B STB1135 STB9135 STM761 STN1135 STR50267 SRJ142 Bosch show 0001110140 ruil 0986018681 11040257 EuroTec 11040607 Cargo EAI 190533092 PSH 252477 Elstock 281000G010 Toyota 281000G020 281000G021 28100B020 28100OG010 28100OG020 335089092 DRI 428000072 Denso 4280000720 4280000721 4280000722 4280000723 4280004350 458260 Valeo 600000170110 Magneti Marelli 63280077010 726122 8018680 Friesen 8018680F 8EA737543001 Hella 918680 EDR CEVAM ATS375 ATK ATS910 F042202533 F042S00274 HJS1135 HC J5212124 LRT182 Lucas N5212113 Nipparts N5212124 OSM11157 Optimum SP4568 Spidan STR8284 Unipoint STRH143 T521A109 NPSSpecifications
| Kilowatt | 2 kW |
| Length (L.1) | 251 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 3 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Avensis 2.0 D | [1CD-FTV] | 09.2002-02.2003 |
| TOYOTA | Avensis 2.0 D-4D | [1CD-FTV] | 09.2002-02.2003 |
| TOYOTA | Avensis 2.0 D-4D | [1CD-FTV] | 10.1999-02.2003 |
| TOYOTA | Avensis 2.0 TD | [2C-TE] | 09.1997-02.2003 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 01.2002-02.2007 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 01.2002-12.2006 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 04.2004-02.2007 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 06.2004-07.2007 |
| TOYOTA | Corolla 2.0 D-4D Verso | [1CD-FTV] | 04.2004- |
Reference Information
PRSL054 S1049B 2810008010 112006 190.533.092.215 5010077 31183N MAV423020A STRL054B CST10113GS J5212117 EAA-121019 25-2477 DS8610 LRS2099 190.533.092.010 11941 EAA-121019-R 458514 DRS7500 JS1135 MAV121130A 1019852 PRSL054B BOS0001110132 28100-0G010 281000B010 DS6460 6010113.2 20401311RC MAV423020 6010113.1 STB1135 STRL054 S0020 DRS8680 MAV121130R 9521 8EA737543-001 STM761 RAS39791 000986018680 1110132 ANM10900X 1057811 20401311OE 0001110132 STR1514 20401311BN 28100-0G021 281000B020 28100-0G020 201067 AES1282 LRS02099 6010113 8EA011610-631 428000-0720 28100-0B010 DRS8680X 986018680 CST10113AS 428000-4350 STRL054NE 7275964 2810001020 STR50267 28100OG020 STA0125R STRL054U CST10113RS 28100-0B020Video/Publications
0001110132 003-T359 063280077010 063521101320 063721135010 0986018680 112006 11941 190.533.092 201135 20401311 20432203 20510182 220094 25-2477 28100-0B010 28100-0B020 28100-0G010 28100-0G020 28100-0G021 31183N 3T359 458514 6.0051.9 6010113 6040302 88212897 8EA011610-631 8EA737543-001 943211351010 944280186800 9521 BOS0001110132 CGB-28680 CST10113 CST10113AS CST10113ES CST10113GS CST10113OS CST10113RS CST40302 CST40302AS CST40302ES CST40302GS CST40302OS CST40302RS DENDSN950 DRS8680 DS9790 EAA-121019 J5212117 JS1135 LRS02099 LRS2099 MAV121130 MRS18680 MS428000-0720 MSN2148 MSN8077 MSRC1135 MTT359 RAS39791 RNL1868 S0020 S1049B STB1135 STB9135 STM761 STN1135 STR50267 STRL054Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
