Associated Numbers
A5137 A3TJ2391 A3TJ0291 A3TJ1091 A3TJ1181 A3TJ1191A A003TJ2391 A003TJ0291 A003TJ1091 A003TJ1181 A003TJ1191ASpecifications
| Amp | 110 A |
| Height (H.1) | 70.1 mm |
| Height (H.2) | 35.1 mm |
| Inside Diameter (I.D.1) | 105.7 mm |
| Lam. Stack Height (H.3) | 26.1 mm |
| No./Leads | 6 qty |
| Outside Diameter (O.D.1) | 136 mm |
| Outside Diameter (O.D.2) | 133 mm |
| Outside Diameter of Windings (O.D.3) | 128.5 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
AFM3091 LFB618W45 UD45876ASVideo/Publications
AFM3091 A5415S A003TJ1191A A3TJ0291 A3TJ4181ZE A3TJ2391 A3TJ1181 A3TJ1191 A5213 A5137 A003TJ1091 A003TJ1181 LFB618W45 A5211 A003TJ2391 A003TJ0291 A3TJ1091 UD45876AS A3TJ1191A A3TJ4081ZE A5397SAdd Your Number
