Associated Numbers
TG8C011 TG8S019 A3220 TG8S012 SG7S015Specifications
Amp | 80 A |
Height (H.1) | 69.2 mm |
Height (H.2) | 30.1 mm |
Inside Diameter (I.D.1) | 92 mm |
No./Leads | 3 qty |
Outside Diameter (O.D.1) | 118 mm |
Outside Diameter of Windings (O.D.3) | 109.8 mm |
Unit Type | VALEO |
Voltage | 12 V |
Reference Information
236395 STA0059 593821 UD01561ASVideo/Publications
236395 593821 TG8C011 TG8S019 A3220 UD01561AS TG8S012 SG7S015 TG8S010Add Your Number
